SOLUTION MANUAL
,
O N E
Introduction
ANSWERS TO REVIEW QUESTIONS
1. Guided missiles, automatic gain control in radio receivers, satellite tracking antenna
2. Yes - power gain, remote control, parameter conversion; No - Expense, complexity
3. Motor, low pass filter, inertia supported between two bearings
4. Closed-loop systems compensate for disturbances by measuring the response, comparing it to
the input response (the desired output), and then correcting the output response.
5. Under the condition that the feedback element is other than unity
6. Actuating signal
7. Multiple subsystems can time share the controller. Any adjustments to the controller can be
implemented with simply software changes.
8. Stability, transient response, and steady-state error
9. Steady-state, transient
10. It follows a growing transient response until the steady-state response is no longer visible. The
system will either destroy itself, reach an equilibrium state because of saturation in driving
amplifiers, or hit limit stops.
11. Natural response
12. Determine the transient response performance of the system.
13. Determine system parameters to meet the transient response specifications for the system.
14. True
15. Transfer function, state-space, differential equations
16. Transfer function - the Laplace transform of the differential equation
State-space - representation of an nth order differential equation as n simultaneous first-order
differential equations
Differential equation - Modeling a system with its differential equation
SOLUTIONS TO PROBLEMS
50 volts
1. Five turns yields 50 v. Therefore K = = 1.59
5x2 rad
Copyright © 2011 by John Wiley & Sons, Inc.
,
1-2 Chapter 1: Introduction
2.
temperature difference difference temperature
flow
+ Amplifier and
Thermostat Heater
valves
-
3.
Desired Input Error Aileron Roll Roll
roll voltage voltage position rate angle
+ Aileron Aircraft
Pilot Integrate
controls
control
-
Gyro
Gyro voltage
4.
Input
Desired voltage Actual
Error Motor
speed + voltage and speed
transducer Amplifier drive
system
-
Dancer
Dancer
position
Voltage sensor dynamics
proportional
to actual speed
Copyright © 2011 by John Wiley & Sons, Inc.
,
1-3 Solutions to Problems
5.
Input Power Rod
Desired voltage Motor Actual
power and power
Transducer
+ Amplifier drive Reactor
system
-
Sensor &
Voltage transducer
proportional
to actual power
6.
Graduating
and
drop-out rate
Desired Net rate Actual
Desired Population student Actual
student
+
population rate
+ Administration Integrate
Admissions
-
7.
Voltage Voltage
proportional representing
to desired Volume actual volume Actual
+ error volume
volume Volume
Transducer Radio
control circuit
-
Effective
volume
+
Voltage
- proportional
to speed
Transducer
-
Speed
Copyright © 2011 by John Wiley & Sons, Inc.
