Terms in this set (193)
What is the voltage found at the TT terminals 24 volts
What are the 8 steps of a no heat call 1 talk to customer 2 check tt.3 check to make sure an emergency switch is on
4check to make sure there is oil in the tank 5 check to make sure the main
power going to the unit is on six check to make sure that tank shut off valve is
open 7 know whether the tank is located above or below the burner I know the
type and style of the system that is being used on a one or two pipe system
What is a cad cell A device containing condominium sulfide used to prove the flame in oil burner
furnace
How much air is needed to burn a gallon of number 2 In 2015 most oil burners are set up to burn with approximately 50% excess air
fuel oil and why. because it would be dangerous to set up a burner for exactly the correct
amount of air
What is the term InStep mean The stack relay is operating correctly
What is normal pump pressure 100 PSI
How is combustion achieved Atomization, air, ignition.
What is primary air and secondary air Primary air, air that is introduced to a furnace burner before the combustion
process has taken place. secondary air, air that is introduced to the furnace
after combustion has taken place and that supports combustion
How should an oil tank be supported It shall be secured attached to a non-combustible supports
What is the wire gauge use an oil burner circuits 14 gauge 15 amp fuse
, How is an oil burner wired Shall be wired on its own circuit. All protective control and emergency devices
shall be series connected in the grounded line conductors. all the electrical
wiring shall be in accordance with 527 CMR 12.00 Massachusetts electrical
code
What size vent pipe is required with a 2 inch fill pipe A fill pipe shall not be greater than the vent pipe. The minimum the fill pipe in
the state of Massachusetts is one and one quarter inch.
Explain interrupted ignition the ignition Transformer drops out of the circuit once a flame is established
What are the elements are found in fuel oil number 2 Carbon hydrogen oxygen and hydrocarbons
What is a BTU A British thermal unit is the amount of heat needed to raise one pound of water
1 degree Fahrenheit
How many BTUs are in one gallon number 2 fuel oil 140,000 BTUs
What determines the gallons per hour of a nozzle Manufacturer ,the bore size, pump pressure or Orphus
What is a series circuit an electrical or piping circuit where all of the current or fluid flows through the
entire circuit
What is a degree day The average temp for the day - 65
What is the flash point of number 2 fuel oil 115 degrees Fahrenheit
When does the law require a combustion efficiency test During installation and maintenance
What controller shuts off the oil burner in the event of The high limit switch
excessive temperature in the appliance
What are the three functions of an oil pump 1- filters 2- pressurizes 3- pumps fuel to the burner
How is an oil burner circuit wired In series on its own circuit
How is oil flow adjusted in a rotary burner Constant level and metering valve
What does InStep mean The stack relay is operating properly
How is combustion achieved Atomization ,air ,ignition.
What is the minimum size oil line for residential burners 3/8 inch
How is safety timing checked on a stack relay switch Remove the stack relay from the duck and let it run .it should shut off in 45
seconds.
What is the safety lockout time on Burner firing under 3 45 seconds
gallons per hour
What control devices are found on gravity feed burners Constant level valve
When is a vent pipe required When the Supply tank is larger than 10 gallons
