CSWA Simulation – Practice & Study Guide for SolidWorks Certification Page 1 2026-03-16
CSWA Simulation – Practice
& Study Guide for
SolidWorks Certification
Guidehttps://www.stuvia.com/dashboard!@_)#*)(@$)($@*($@)($@*_
CSWA Simulation – Practice & Study Guide for SolidWorks Certification.pdf 1 CSWA Simulation – Practice & Study Guide for SolidWorks Certification.pdf
,CSWA Simulation Page 2 2026-03-16
True
False
Don't know?
Terms (67)
Hide definitions
h-method of meshing involves
increasing mesh density
p-method of meshing involves
increasing mesh element polynomial order
CSWA Simulation.pdf 2 CSWA Simulation.pdf
, CSWA Simulation Page 3 2026-03-16
is it possible to model breaking of glass on the floor using linear static analysis?
no
which of the following cases, the rope will most likely break?
both are the same
Assuming a linear static study, if the Young's modulus of the material is doubles (everything else remains the same),
then the tensile stress will be
doubles
iso lot in the simulation will enable to
set lower and upper limits to see desired stress range
which statement best describes a compatible mesh?
a mesh where elements on touching bodies have overlaying nodes
CSWA Simulation.pdf 3 CSWA Simulation.pdf
