2026 UPDATED QUESTIONS DOWNLOAD
Medical Gas Systems Refresher 300 Questions,
Answers, & Rationales (NFPA 99 Standards)
This comprehensive Med Gas Refresher Exam study guide provides 300 high-quality multiple-
choice questions designed to prepare professionals for ASSE 6010, 6040, and
6030 recertification. Each question includes a bolded answer and a detailed italicized
rationale based on the latest NFPA 99 Health Care Facilities Code standards. It serves as an
essential resource for mastering critical topics such as system risk categories, brazing
protocols, alarm monitoring, and mandatory safety testing.
1. According to NFPA 99, which Risk Category describes a system failure that is
likely to cause major injury or death to patients?
A) Category 3
B) Category 2
C) Category 1
D) Category 4
Rationale: Category 1 systems are those in which failure is likely to cause major injury
or death to patients or caregivers.
2. What is the required change in line pressure that must trigger a local area
alarm?
A)
5%
B)
10%
C)
20%
D)
,2026 UPDATED QUESTIONS DOWNLOAD
50%
Rationale: Area alarms must notify staff when the pressure in a specific zone varies by
more than 20% from the normal operating pressure.
3. Which gas must be used for the initial pressure test and for purging during
brazing?
A) Oxygen
B) Compressed Air
C) Carbon Dioxide
D) Oil-free Dry Nitrogen
Rationale: Oil-free Dry Nitrogen is inert and prevents oxidation (scale) inside the pipe
during the brazing process.
4. What is the standard color-coding for a Medical Air pipeline in the United
States?
A) Green
B) Blue
C) Yellow
D) White
Rationale: In the US, Yellow identifies Medical Air; Green is Oxygen, and Blue is
Nitrous Oxide.
5. The "Source Valve" in a medical gas system is located at which point?
A) At each patient outlet
B) At the entrance to each Operating Room
C) At the immediate connection of the supply source to the distribution piping
D) On the roof exhaust
Rationale: The Source Valve allows the entire distribution network to be shut off from
the supply source.
6. Before a new medical gas system is put into service, what must be performed
to ensure no cross-connections exist?
A) Smell test
B) Sound test
C) Cross-connection test with individual gas analysis
D) Visual inspection
Rationale: A Cross-connection test ensures that the gas delivered at each outlet
matches the label specified.
7. Master alarm panels must be located in at least how many separate locations?
A) Two
,2026 UPDATED QUESTIONS DOWNLOAD
B) One
C) Three
D) Four
Rationale: NFPA 99 requires master alarms to be in two separate locations to ensure
24/7 monitoring.
8. When brazing medical gas joints, what is the required filler metal?
A) Lead-based solder
B) BCuP series (Silver Brazing Alloy)
C) Soft solder
D) Zinc coating
Rationale: BCuP series filler metals are used without flux to prevent internal
contamination.
9. What is the minimum required pressure for the initial leak test of a Category 1
positive pressure system?
A) 50 psig
B) 100 psig
C) 1.5 times the working pressure (but not less than 150 psig)
D) 200 psig
Rationale: The initial pressure test must be conducted at 1.5 times the system
working pressure.
10. A "Zone Valve" serves what primary purpose?
A) To shut off gas to a specific area for maintenance or emergency
B) To regulate building pressure
C) To start backup generators
D) To vent gas
Rationale: Zone Valves isolate specific sections of a hospital without cutting off gas to
the entire facility.
11. Which organization sets the standards for medical gas piping systems?
A) OSHA
B) NFPA
C) EPA
D) FDA
Rationale: The NFPA (National Fire Protection Association) 99 code is the primary
standard for healthcare facilities.
12. Medical gas cylinders must be stored in rooms that are:
A) Unventilated
, 2026 UPDATED QUESTIONS DOWNLOAD
B) Well-ventilated and constructed of non-combustible materials
C) Kept at freezing temperatures
D) Labeled as "Open Access"
Rationale: Proper ventilation prevents the buildup of leaked gases which could pose
fire or asphyxiation risks.
13. What is the maximum distance between labels on a medical gas pipeline?
A) 5 feet
B) 20 feet
C) 50 feet
D) 100 feet
Rationale: Pipelines must be labeled at intervals not exceeding 20 feet and in every
room or at every floor penetration.
14. What is the standard operating pressure for Nitrogen (used for driving tools)?
A) 50-55 psig
B) 100 psig
C) 160-185 psig
D) 300 psig
Rationale: Unlike life-support gases (50-55 psig), Nitrogen for power tools operates at
much higher pressures.
15. A "Main Valve" is located where?
A) Outside of the source building at the point of entry
B) In the patient's room
C) On the alarm panel
D) Under the sink
Rationale: The Main Valve is located where the source piping enters the facility.
16. WAGD stands for:
A) Water and Gas Distribution
B) Waste Anesthetic Gas Disposal
C) Wide Area Gas Detection
D) Warning Alarm for Gas Depletion
Rationale: WAGD systems safely remove anesthetic gases from operating rooms to the
outside atmosphere.
17. What color is the label for Oxygen in the US?
A) Green
B) Blue
C) Yellow
