UH60M LIMITS EXAM QUESTIONS AND
ANSWERS GRADED A+ 2026
Any time an operational limit is exceeded, an appropriate entry shall be made on DA Form
_______. Entry shall state what limit or limits were _______, ______, ___________, and any
additional data that would aid maintenance personnel in the maintenance action that may be
required. The helicopter shall not be ________ until corrective action is taken. - ANS 2408-
13-1
exceeded, range, time beyond limits
flown
Red and Yellow striped tapes and red readouts indicate the limit is _____________________.
Yellow tapes and readouts indicate_______________.
Green tapes and readouts indicate the______________. - ANS likely to cause damage or
shorten component life.
the range when special attention should be given to the parameter the instrument represents.
the normal operating range of the parameter the instrument represents.
Operating an engine against the gust lock is ________ - ANS Prohibited
Maximum rotor speed for emergency rotor brake applications is ____ NR. - ANS 76%
@COPYRIGHT 2026/2027 ALLRIGHTS RESERVED 1
, Routine stops will be with engine(s) off, NR below ___% and with _____ - ______ psi applied to
stop the rotor in not less than ___ seconds. - ANS 40%
150-180 psi
12 seconds
Minimum rotor brake pressure for engine start is ___ psi. Maximum rotor brake pressure for
engine start is ___ psi. - ANS 450 psi
690 psi
Use of the rotor brake with engine(s) operating is restricted to ______ and ____ engine starts
and operations at ____ only. - ANS single
dual
IDLE
Single and dual engine starts and operation at ____ with rotor brake on are not time limited. -
ANS IDLE
Single-engine operation with gust lock engaged will be performed by authorized pilot(s) at ____
only. - ANS IDLE
(Transmission) oil pressure should remain steady and should be in the ____ - ____ range to
ensure that when fluctuations occur, they remain in the acceptable range... - ANS 45-60 psi
If (transmission) oil pressure is not steady during steady state forward flight or in a level hover,
or if oil pressure is steady but under ___ psi, make an entry on the appropriate maintenance
form. Sudden pressure drop (more than ___ psi) without fluctuation requires an entry on the
appropriate maintenance form. - ANS 45 psi
10 psi
NP1 / NP2 - ANS 12 sec Trans: 105-107%
Transient: 101-105%
@COPYRIGHT 2026/2027 ALLRIGHTS RESERVED 2
