0 1 MOSFETs are widely used as electronic switches in modern circuits due to their
efficiency and versatility. A student is investigating the operation of an n-channel
MOSFET. Figure 1 shows the internal structure of an n channel MOSFET with its
terminals labelled.
Figure 1
0 1 . 1 Explain what is meant by a depletion zone in a p-n junction and describe its electrical
behaviour.
[3 marks]
for more: tyrionpapers.com
, Figure 2 shows the characteristic graph of the MOSFET input.
Figure 2
The MOSFET has a threshold voltage Vth = 2.0 V and is connected to a supply
voltage of 9 V. The gate voltage VGS is increased from 0 V.
0 1 . 2 State what happens to the drain-source current IDS when VGS is below Vth.
Explain your answer.
[2 marks]
