MSSC - QUALITY CERTIFICATION
EXAM QUESTIONS AND ANSWERS 2026
VERIFIED.
Which is NOT one of the steps used in the glass box method? - ANS rotate object in glass box
The three standard views of an object are ______. - ANS top, front, right side
What is the order of precedence of lines in a drawing? - ANS object, hidden, center
What type of feature is parallel to the surface being dimensioned? - ANS dimension line
A ______ dimension is described in inches per foot. - ANS shaft taper
To establish on a drawing that 1/4 inch equals 1 inch, the designer would write ______. -
ANS 1/4 = 1
Section lines on a blueprint include _______. - ANS a surface that has been cut
In a threaded fastener assembly what is designed to protect the threads? - ANS shank
@2026/2027 ALLRIGHTS RESERVED.
, The minor diameter of a screw thread is measured at the ______. - ANS root of screw thread
The minor diameter of a threaded fastener is ______. - ANS the major diameter minus the
thread height
How do you determine the grade of a bolt? - ANS number of lines on the head +2 indicates
the grade
A screw with National fine thread is represented on a drawing with what designation? -
ANS NF
Metals treated by ______ processes become soft. - ANS annealing
A running fit is also called a(n) ______. - ANS sliding fit
The term ______ refers to a physical portion of a part. - ANS feature
A(n) _______ is a theoretically perfect line, point or pane that is located by a similar feature or
part. - ANS datum
GD&T _________________. - ANS allows certain tolerances on part features to be increased
A feature control frame is not used to describe ______. - ANS measurements
A common decimal inch rule graduation is in _______. - ANS 50ths
@2026/2027 ALLRIGHTS RESERVED.
