,TO READER
This manual has been printed for a skilful engi- CNH AMERICA LLC
neer to supply necessary technical information to 245 E North Avenue
carry out service operations on this machine. Carol Stream, II 60188 U.S.A.
Read carefully this manual to collect correct infor-
mation relevant to repair procedures.
For any question or remark, or in case of any
error relevant the contents of this manual, please
contact:




REFERENCES
Beyond this Service Manual, also refer to the
documents listed below:
- Operator’s Manual
- Service Parts Catalogue




SERVICE MANUAL The Service Manuals for “Loader backhoe” and
“Engine” contain the necessary technical informa-
The Service Manual consists of two volumes:
tion to carry out service and repair on machine
- B90B - B95B - B95BLR - B95BTC - B110B - and on engine, necessary tools to carry out those
B115B operations and information on service standard,
Service Manual for “Loader backhoe” on procedures for connection, disconnection, dis-
- B90B - B95B - B95BLR - B95BTC - B110B - assembly and assembly of parts.
B115B The Service Manual which covers the loader
Service Manual for “Engine” backhoe models B90B - B95B - B95BLR -
B95BTC - B110B - B115B consists of the follow-
ing volumes, which can be identified by their print
number as stated below:


VOLUME MACHINE TYPE PRINT NUMBER
Service Manual for “Loader backhoe” B90B - B95B - B95BLR - B95BTC - B110B - B115B 84428670A1
Service Manual - “Engine” B90B - B95B - B95BLR - B95BTC - B110B - B115B 87659057A

, PREVENT ACCIDENTS
The majority of accidents and injuries which occur in the workshop, at the worksite or on the road, are caused
by the failure of some individual to follow simple and fundamental safety rules or precautions. For this reason
most accidents can be prevented by recognizing the real cause and taking the necessary precautions, before
the accident occurs.


Regardless of the care used in design and construction of any type of equipment, there may be conditions
that cannot be completely safeguarded against, without interfering with reasonable accessibility and efficient
operation.


A careful operator and / or technician is the best insurance against accidents.
The careful observance of this single safety rule would be sufficient to prevent serious injuries:


Never attempt to clean, lubricate or adjust a machine while it is in motion.



S WARNING S
Before carrying out any maintenance operation, adjustment and or repair on machines equipped with attach-
ments, controlled hydraulically or mechanically, make sure that the attachment is lowered and safely set on
the ground. If it is necessary to have the equipment partially or fully raised to gain access to certain items, be
sure the equipment is suitably supported by means other than the hydraulic lift cylinders, cable and /or
mechanical device used for controlling the equipment.




CNH AMERICA LLC
245 E North Avenue
Carol Stream, II 60188 U.S.A.


All rights reserved. Reproduction of text or illustrations, in whole or in part, is strictly prohibited.

, LOADER BACKHOE MODELS
The complete range of Loader Backhoe models described in this manual are identified below:

B90B B95B B95BTC B110B B115B
B95BLR
Powershift / / /  


Powershuttle     /
Cab     


Rops    / /
2WD   / / /
4WD     


4WS / / / / 


“Pilot” backhoe attachment controls     


Backhoe attachment mechanical controls     


Engine Iveco 72 kW - 97 HP model
 / / / /
F4GE9424C*601 (mechanical)
Engine Iveco 72 kW - 97 HP model
/   / /
F4HE0484G*J102 (electronic)
Engine Iveco 82 kW - 110 HP model
/ / /  /
F4HE9484C*J102 (electronic)
Engine Iveco 82 kW - 110 HP (4WS) model
/ / / / 
F4HE9484C*J103 (electronic)
Short dipper backhoe    / /
Long dipper backhoe /    
