Maryland Stationary Engineer Grade 1 Practice Exam 2026



• This 200-question practice exam mirrors the actual Maryland Stationary Engineer
Grade 1 licensing exam, covering boiler operations, safety codes, steam systems,
water treatment, fuel systems, and emergency procedures — use it to test yourself
section by section, then review every EXPERT RATIONALE carefully to reinforce
understanding.

• Each question includes five answer choices (A–E), a clearly highlighted correct
answer, and a detailed EXPERT RATIONALE — making this a complete self-study
tool you can use repeatedly until exam-ready.



QUESTION 1: What is the primary purpose of a safety valve on a boiler?

A) To regulate steam pressure during normal operation

B) To drain condensate from the system

C) To allow air into the boiler during shutdown

D) To measure the water level in the boiler drum

E) To control fuel flow to the burner

CORRECT ANSWER: A) To regulate steam pressure during normal operation

EXPERT RATIONALE: A safety valve automatically opens when boiler pressure exceeds
the maximum allowable working pressure (MAWP), releasing steam to prevent
catastrophic failure. It is the most critical safety device on a boiler.



QUESTION 2: According to ASME code, safety valves on steam boilers must be
set to open at no more than:

,A) 10% above the design pressure

B) 15% above the MAWP or 3 psi above, whichever is greater

C) 25% above the operating pressure

D) Exactly at the operating pressure

E) 50 psi above the working pressure

CORRECT ANSWER: B) 15% above the MAWP or 3 psi above, whichever is
greater

EXPERT RATIONALE: ASME Boiler and Pressure Vessel Code requires safety valves to be
set no higher than 15% or 3 psi above MAWP, whichever is greater, ensuring safe
pressure relief before dangerous levels are reached.



QUESTION 3: The term "MAWP" stands for:

A) Maximum Allowable Water Pressure

B) Minimum Allowable Working Pressure

C) Maximum Allowable Working Pressure

D) Measured Actual Water Pressure

E) Maximum Applied Water Power

CORRECT ANSWER: C) Maximum Allowable Working Pressure

EXPERT RATIONALE: MAWP is the maximum pressure at which a boiler or pressure
vessel is designed to operate safely, as stamped on the nameplate and certified by the
manufacturer per ASME code.



QUESTION 4: What does a low-water fuel cutoff (LWCO) device do?

A) Reduces fuel pressure when water temperature drops

B) Shuts off the fuel supply when boiler water drops to an unsafe level

,C) Opens the safety valve when water level is low

D) Increases burner firing rate to restore water temperature

E) Activates the feedwater pump only during high-pressure conditions

CORRECT ANSWER: B) Shuts off the fuel supply when boiler water drops to
an unsafe level

EXPERT RATIONALE: The LWCO is a critical safety control that automatically cuts fuel to
the burner when water falls below a safe operating level, preventing overheating, metal
damage, and potential boiler explosion.



QUESTION 5: Which type of boiler is most commonly used for high-pressure
steam generation in large commercial facilities?

A) Cast iron sectional boiler

B) Electric resistance boiler

C) Fire-tube boiler

D) Water-tube boiler

E) Condensing boiler

CORRECT ANSWER: D) Water-tube boiler

EXPERT RATIONALE: Water-tube boilers, where water flows inside tubes surrounded by
hot gases, are preferred for high-pressure, high-capacity applications because they can
withstand greater pressures and respond more quickly to load changes.



QUESTION 6: In a fire-tube boiler, hot gases travel:

A) Through tubes surrounded by water

B) Around the outside of water-filled tubes

C) Through a separate heat exchanger

D) Directly into the steam drum

, E) Through a refractory-lined combustion chamber only

CORRECT ANSWER: A) Through tubes surrounded by water

EXPERT RATIONALE: In a fire-tube boiler, combustion gases pass through tubes that are
immersed in water. The heat from the gases transfers through the tube walls to the
surrounding water, generating steam.



QUESTION 7: What is the function of a feedwater regulator?

A) To control the pH of boiler water

B) To maintain a consistent water level in the boiler drum

C) To regulate the temperature of incoming feedwater

D) To prevent steam from entering the feedwater line

E) To filter sediment from boiler water

CORRECT ANSWER: B) To maintain a consistent water level in the boiler
drum

EXPERT RATIONALE: A feedwater regulator automatically controls the flow of feedwater
into the boiler to maintain a safe and steady water level, preventing both low-water and
high-water conditions.



QUESTION 8: Which chemical is commonly used in boiler water treatment to
control scale formation?

A) Sodium hypochlorite

B) Hydrochloric acid

C) Phosphate compounds

D) Calcium chloride

E) Potassium permanganate

CORRECT ANSWER: C) Phosphate compounds
