ENDEAVOR MV ORAL EXAM
QUESTIONS AND ANSWERS
Can you flex if FMS 1 and 2 are INOP? - Correct Answers --Yes, EICAS menu page
using the EICAS control panel
-Delete flex temp by selecting the FLX RESET on EICAS menu page
If the MFD fails, can you display it on another screen? - Correct Answers -No
Why isn't there a checklist for an ED1 failure? - Correct Answers -It transfers
automatically
Can you tune COM 1 and NAV 1 from RTU 2? How? - Correct Answers --Yes, by
pressing the 1/2 button on RTU 2
-Cross-side RTU information is displayed in amber
Windshield heat usage? - Correct Answers --On below 30
-Off above 30 (On ground)
-High for deicing
If you have a 100 foot taxiway clearance, can you taxi on that taxiway? - Correct
Answers --Yes
-700: 76.27 feet
-900: 81.6 feet
Turning radius for 700/900? - Correct Answers --700: 75 feet
-900: 80 feet
Tire speeds for 700/900? - Correct Answers --700: 182kt
-900: 195kt
Approach category for 700/900? - Correct Answers --700: Category C
-900: Category D
-Reduced REF: Category C
What are the cabin pressure modes? - Correct Answers -Auto and manual
Can you manually switch pressure controllers? What happens if you just press manual
once? - Correct Answers --Press the PRESS CONT twice
,-Pressure controller is in manual
When your pneumatics are closed, what do you lose? - Correct Answers -Engine starts,
packs, pressurization, and anti-ice
When does HYD 1B and HYD 2B come on in auto? - Correct Answers --Flaps greater
than 0
-Any generator is operating
-Respective buses are powered
If the ADG deploys, what will happen to hydraulic system 3? - Correct Answers -Pump
3B will operate automatically regardless of switch position
When is the only time the hydraulic B pumps turn on? - Correct Answers --Respective
buses are powered
-Any generator is operating
-Flaps are not at 0 degrees
When will the ADG deploy? - Correct Answers --Loss of all AC
-When AC BUS 1 and AC BUS 2 are unpowered
-No weight-on-wheels
-An aircraft generator was the last power source online
What happens when you pass VMO/MMO? - Correct Answers --Overspeed clacker
sounds
Where does the APU get fuel from? - Correct Answers -Left collector tank
What is the difference between taxiing with the tiller and taxiing with the rudder? -
Correct Answers --Tiller: 80 degrees either side of center (low speed taxi)
-Rudder: 8 degrees either side of center (high speed taxi/takeoff/landing)
When will the fire extinguisher put the fire out in the LAV? - Correct Answers -Two heat
sensitive capsules that melt and release the halon into the waste bin automatically
What step on the pushback procedure turns on the FDR? - Correct Answers --Beacon
-Strobes on or WoW activates FDR also
How do you identify a localizer if it doesn't appear on the PFD? - Correct Answers -
Morse code
What information does the FMS give? - Correct Answers --RNP
-Radio
-Navigation
-Performance
, What prevents the tires from locking up? - Correct Answers --Anti-skid system
-Prevents skids from developing
-Prevents landing with locked wheels
-Activates once a 35-knot wheel spin-up signal is present or WoW signal is present after
a 5 second delay
What does the EMER FLAP switch do? - Correct Answers --900: Slats first extend to
the 20-degree position
-700: Slats first extend to the 25-degree position
-Flaps move to the 20-degree position
-Inhibited above Vfe 20 speed (230 or 220)
How many exits are on the aircraft? - Correct Answers -7
What does the FAULT light mean on the IDG? - Correct Answers --A fault has occurred
within the IDG
-HOTLOP
-High oil temp, low oil press
What does the AC ESS XFER switch light mean? - Correct Answers --Used to switch
AC ESS BUS 1 to AC ESS BUS 2
-Transfer is automatic during an AC BUS 1 failure
How do we do a bleeds closed takeoff? When do the bleeds switch to engines on
takeoff? - Correct Answers --APU On or unpressurized if APU is INOP
-Takeoff bit
=Thrust levers out of TOGA
=Landing gear is up
=Flaps 20 or less
=(About 20 seconds to complete)
When do the bleeds switch back to the APU on landing? - Correct Answers --Landing
bit
=Flaps are greater than 20 OR
=Landing gear is down
=(About 20 seconds to complete)
What does the EMER/NORM button mean on the RTU panel? - Correct Answers --
Bypasses audio control panel and directly connects to the respective VHF and NAV
(CA: VHF and NAV 1, FO: VHF 2 and NAV 2)
Can you cross side tune if you lose an RTU? - Correct Answers -Yes, RTU INHIB
switch on non-working RTU side then select the 1/2 button on the working RTU
What will you see if you select the opposite side AIR DATA switch? - Correct Answers --
Amber ADC 1
