ASE A6 CERTIFICATION PRACTICE EXAMINATION (2025/2026 EDITION)
ELECTRICAL / ELECTRONIC SYSTEMS – THEORY, DIAGNOSIS, TESTING,
AND REPAIR PROCEDURES OFFICIAL PRACTICE ASSESSMENT PAPER
ADVANCED AUTOMOTIVE ELECTRICAL AND ELECTRONIC SYSTEMS
TECHNOLOGY REVIEW
Basic electrical theory | ohm’s law application | circuit analysis |
battery systems | starting systems | charging systems (alternator
operation) | wiring diagram interpretation | relays, switches, and
fuses | lighting systems
At the front of the vehicle. Technician B says to disconnect and isolate the negative battery
cable.
Who is right?
A. Technician A only
B. Technician B only
C. Both A and B
D. Neither A or B
.B
Which of these should be used when soldering electrician wiring connections?
A. rosin core flux
B. acid core flux
1|Page
,C. sulfur core flux
D. none of the above
.a
When testing computer-controlled systems, a digital multimeter should be used with an input
impedance of at least:
A. lOk ohms
B. lOOk ohms
C. 1 megohm
D. 10 megohms
.d
When troubleshooting a slow drain on the battery, which if these diagnostic tools should be
used?
A. Ohmmeter
B. Ammeter
C. Voltmeter
D. Test fight
.b
The condition of a lead-acid battery is being checked. Technician A says to use a galvanometer.
Technician B says to use a capacitive battery tester.
2|Page
,Who is right?
A. Technician A only
B. Technician B only
C. Both A and B
D. Neither A or B
.b
While testing a starting circuit on a 5.7L V8 engine, the technician finds that the engine cranks
slowly. The
starter current draw is 90 amps, and the battery voltage while cranking is 11 volts. What should
the technician do next?
A. Check for voltage drop of the starter motor circuit.
B. Test the battery capacity.
C. Replace the starter motor, as a short Is indicated.
D. Determine the condition of the engine.
.a
Technician A says that a noisy alternator could be caused by a bad diode. Technician B says that
a noisy alternator could be caused by a worn bearing.
Who is right?
A. Technician A only
B. Technician B only
3|Page
, C. Both A and B
D. Neither A or B
.c
The analog ohmmeter needle does not move when connected as shown above. (pg 82) This
indicates that the rotor winding is:
A. shorted
B. grounded
C. complete
D. open
.d
A vehicle's tum signals flash too slowly. Technician A claims that the condition could be caused
by a faulty flasher. Technician B says that a bulb may be the wrong type.
Who is right?
A. Technician A only
B. Technician B only
C. Both A and B
D. Neither A or B
.c
4|Page
