When the ignition is first turned on a click noise is heard Tech A Only (Pg 995)
from under the hood of a vehicle equipped with ETC.
Technician A says that this is the normal operation of the
ETC self-test. Technician B says that the ETC motor
should not move unless the engine is running. Which
technician is correct?
Identify the throttle position sensor assembly in this A (Pg 994)
diagram.
Which component in this photograph is the drive (motor) A (Pg 956)
gear?
The throttle plate actuator motor is what type of electric DC Motor (Pg 955)
motor?
Engine Performance 2.pdf Engine Performance 2.pdf Engine Performance 2.pdf
, Engine Performance 2.pdf Engine Performance 2.pdf Engine Performance 2.pdf
With the ignition off and the key out of the ignition, what The throttle should move, and then spring back to the home position when
should happen if a technician uses a screwdriver to released. (Pg 958)
gently push on the throttle plate in an attempt to open
the valve?
The throttle body may be cleaned (if recommended by Any of the above (Pg 959)
the vehicle manufacturer) if what conditions are
occurring?
The accelerator pedal position sensor uses ________ Two to three (Pg 954)
sensor(s), which acts to give accurate accelerator pedal
position information to the controller.
The accelerator position sensor outputs 2 identical, False (Pg 954)
redundant voltage signals.
The ETC actuator motor is controlled by the PCM H-bridge (Pg 954)
through what type of circuit?
