What vehicle architectures use an automatic process to
transfer ECU configuration? Select all that apply. ✓ ✓ ......
ANSWER ....... PowerNet
TIPM
, Page 2 of 15
What vehicle architectures use a manual process in the
scan tool to program ECU PROXI configuration? Select all
that apply. ✓ ✓ ...... ANSWER .......
What is the resistance of the terminating resistor on
networks equipped with one star connector? ✓ ✓ ......
ANSWER ....... 60 ohms (Normal CAN Bus terminating
resistance)
With the bus active and no faults present, what voltages
should be measured on CAN-C (-)? ✓ ✓ ...... ANSWER .......
Not Approximately 4.8V
1.3-2.3V
Which of the following vehicles are equipped with the
Atlantis architecture? Select all that apply. ✓ ✓ ......
ANSWER ....... Jeep renegade
Jeep compass
Alfa Giulia
Alfa Stelvio
