AND Gate
Digital circuit that implements the AND operation. The output of this circuit is HIGH only if all of its inputs are HIGH.
Boolean Expression
An algebraic expression made up of Boolean variables and operators, such as AND (-), OR (+), or NOT (-). Also referred to as Boolean
function or a logic function.
Clocked D Flip-Flop
Type of flip-flop in which the D (data) input is the synchronous input.
Combinational Logic
Digital circuitry in which an output is derived from the combination of inputs, independent of the order in which they are applied.
