** An MOV burns out, you replace it but cannot read Replace it with a larger one (630)
voltage or resistance. What should you do?
* On a Ward-Leonard circuit, the brake is set but the motor Suicide circuit (425)
is trying to slip through the brake. What circuit is the issue?
** A Hydro runs up with no load but does not run up with The relief valve is set too low (805)
a full load. What is the issue?
** Runby for a 1:1 car hits the CWT buffer 4" below the top 22" for 1:1.
landing. The CWT runby should be set at 18". How much For a 2:1 with the same issue is 44".
should the ropes be shortened?
** You need to work on a freight door retiring cam. You Mainline disconnect (535)
LOTO the mainline disconnect but there is still power to
the cam. What circuit is still hot?
** The contractor requests that the vertical center of the Adjust Tie downs/Wall ties (805)
Rack and Pinion hoist be moved. How is this
accomplished?
Mechanics Exam.pdf Mechanics Exam.pdf Mechanics Exam.pdf
, Mechanics Exam.pdf Mechanics Exam.pdf Mechanics Exam.pdf
** Working pressure on a Hydro is 400 PSI. What is the 600 PSI Max. (805)
correct Relief Valve Setting? 400 psi x 150% = 600 psi
** A contractor wants to raise the car speed from 100 FPM 15"
to 125 FPM. It currently has a 12" sheave. What size sheave (125 /100 = 1.25 1.25 x 12 = 15)
is required?
** There is slight arcing at the Brushes and Commutator. None. (430)
What actions must be taken? "Heavy arcing is due to light brush pressure. Mechanical wear indicates heavy
brush pressure.
** How much resistance is normally measured across a 1.2 ohms or 1 to 2 ohms
normally closed switch ?
** A car traveling in the hoistway always stops at the same Traveling cable has a cut or short
point and blows a fuse. What is the problem?
** How is a Class 1 (yearly) buffer test performed? At slow speed and the buffer must return in 90 seconds. (555) *(60 seconds is
acceptable) (90 seconds is code)
5 year test (Class 5) is car at rated load and speed. Buffer must return in 90
seconds. CWT at rated speed and buffer must return in 90 seconds.
