ERJ-175 Systems Test_ Fuel, Fire, and
Emergency Procedures
2026-2027
Expert-Verified Questions and Answers
(With A+ Grades Guarantee)
,What is the maximum fuel capacity in The maximum fuel capacity in the ERJ-175 is
the ERJ-175? 69,886 lbs.
Is it true that the only way to close the True.
engine fuel shutoff in the event of an
engine fire is by turning off the AC
and DC fuel pumps?
How many fuel pumps are in the left There is 1 fuel pump in the left wing collector tank.
wing collector tank?
What pilot action should be taken in Both A & B are correct: No action is required if the
regards to the anti-icing system and ice detectors are functioning properly or if the REF
taxiing on a contaminated surface A/I was set to ENG or ALL in the MCDU prior to
after landing in a snowstorm? departure.
What conditions will extinguish the The striped bar will extinguish if flaps are greater
striped bar on the water dump than 0, the override button on the FA panel is
button? pressed, there is a faulty drain mast heater
indication in the aft FA control panel, the landing
gear is extended, or the water dump button is
pressed again.
When do the ADS probe heaters The ADS probe heaters automatically turn on when
automatically turn on? AC power is established.
What is the first step to open the Lift the vent flap and escape slide levers, then lift the
MCD from the inside during normal main handle.
operations?
What types of fire can a halon fire A halon fire extinguisher can be used for Class A
extinguisher be used for? (paper, wood, fabric, rubber), Class B (oils, grease,
flammable liquids), and Class C (electrical) fires.
What can interrupt the Electrical Interruption of AC power supply, pressurizing the
Power Up Built In Test (E-PBIT)? hydraulic system, moving the flight controls, or
pressing any FCM button can interrupt the E-PBIT.
, What is true after starting engine #1 Elevators, ailerons, and rudders indicate travel in the
with push complete? correct directions.
Does the EGPWS provide only aural False.
warnings to help pilots avoid terrain?
Is the aircraft equipped with stall True.
detection that pairs with the FD to
provide escape guidance during a
stall?
What does a Cyan Advisory message It indicates operational or airplane conditions that
on the EICAS indicate? require crew awareness, and subsequent or future
crew action may be required.
Can the terrain awareness display be True.
used as a source of navigation?
What type of procedures are This is a memory item.
associated with a 'BATT 1
OVERTEMP' message on the
EICAS?
What should be displayed for a radar Green TO (Active A/T mode), White ROLL (Active
vectored departure after verifying lateral mode), and Green TO (Active vertical mode).
RWY HDG?
What must be set to allow the aircraft VNAV must be active.
to automatically transition to PTH
mode once reaching TOD?
Where will the EICAS information be The information will be displayed on DU1, DU2, or
displayed if DU3 has failed? DU4.
What is the recommended speed to Green Dot + 10 knots.
reference to extend the flaps after an
emergency situation requires an
immediate return to the field?
