IP Addressing
and
Subnetting
Workbook
Version 1.1
11111110
10010101
00011011
10000110
11010011
, IP Address Classes
Class A 1 – 127 (Network 127 is reserved for loopback and internal testing)
Leading bit pattern 0 00000000.00000000.00000000.00000000
Network . Host . Host . Host
Class B 128 – 191 Leading bit pattern 10 10000000.00000000.00000000.00000000
Network . Network . Host . Host
Class C 192 – 223 Leading bit pattern 110 11000000.00000000.00000000.00000000
Network . Network . Network . Host
Class D 224 – 239 (Reserved for multicast)
Class E 240 – 255 (Reserved for experimental, used for research)
Private Address Space
Class A 10.0.0.0 to 10.255.255.255
Class B 172.16.0.0 to 172.31.255.255
Class C 192.168.0.0 to 192.168.255.255
Default Subnet Masks
Class A 255.0.0.0
Class B 255.255.0.0
Class C 255.255.255.0
Produced by: Robb Jones
Frederick County Career & Technology Center
Cisco Networking Academy
Frederick County Public Schools
Frederick, Maryland, USA
Special Thanks to Melvin Baker and Jim Dorsch
for taking the time to check this workbook for errors.
Inside Cover
, Binary To Decimal Conversion
128 64 32 16 8 4 2 1 Answers Scratch Area
1 0 0 1 0 0 1 0 146 128 64
16 32
0 1 1 1 0 1 1 1 119 2 16
146 4
1 1 1 1 1 1 1 1 2
1
1 1 0 0 0 1 0 1 119
1 1 1 1 0 1 1 0
0 0 0 1 0 0 1 1
1 0 0 0 0 0 0 1
0 0 1 1 0 0 0 1
0 1 1 1 1 0 0 0
1 1 1 1 0 0 0 0
0 0 1 1 1 0 1 1
0 0 0 0 0 1 1 1
00011011
10101010
01101111
11111000
00100000
01010101
00111110
00000011
11101101
11000000
1
, Decimal To Binary Conversion
Use all 8 bits for each problem
128 64 32 16 8 4 2 1 = 255 Scratch Area
1 1 1 0 1 1 1 0
_________________________________________ 238 238 34
-128 -32
0 0 1 0 0 0 1 0
_________________________________________ 34 110 2
-64 -2
_________________________________________ 123 46 0
-32
_________________________________________ 50 14
-8
_________________________________________ 255 6
-4
_________________________________________ 200 2
-2
_________________________________________ 10 0
_________________________________________ 138
_________________________________________ 1
_________________________________________ 13
_________________________________________ 250
_________________________________________ 107
_________________________________________ 224
_________________________________________ 114
_________________________________________ 192
_________________________________________ 172
_________________________________________ 100
_________________________________________ 119
_________________________________________ 57
_________________________________________ 98
_________________________________________ 179
_________________________________________ 2
2
