ADDA Mechanical Drafter Certification Practice - Part I Exam With Complete Solutions 2024

orthographic - correct answer-A multiview drawing is also known a(n) __________ drawing. auxiliary - correct answer-A(n) __________ view is projected from an inclined surface. section - correct answer-A(n) __________ view allows you to see the interior of an object. removed - correct answer-A(n) __________ section is usually not aligned with a the primary view. offset - correct answer-A(n) __________ section shows interior features not in a straight line by bending the cutting plane line at 90° angles. viewing plane line - correct answer-The __________ indicates the position of a removed view and line of sight. cutting plane line - correct answer-The line showing where an object is cut for a section and line of sight is the __________. size - correct answer-An object can be made if its __________ and shape are fully-described. shape - correct answer-An object can be made if its size and __________ are fully-described. bevel - correct answer-A(n) __________ is a slanted surface along a straight edge. chamfer - correct answer-A(n) __________ is a slanted surface along a hole or the end of a cylinder. center - correct answer-Chain lines show projected tolerance zones and are drawn as a thick __________ line. dimension - correct answer-A(n) __________ linetype includes arrowheads and is commonly paired with extension lines. 60 - correct answer-The depth lines for an oblique pictorial view are usually drawn at 30 to __ degrees to the horizontal.
