1 This shows a USB-powered personal mini fan.


DC motor




flexible stem
fan blade




USB


(a) The flexible stem of the personal mini fan is covered with PVC. PVC is a thermo softening
polymer.

Identify two reasons why a thermo softening polymer is a suitable material for the flexible
stem.

1 ................................................................................................................................................

...................................................................................................................................................

2 ................................................................................................................................................

...................................................................................................................................................
[2]

(b) Explain why bearings are needed in mechanical systems such as those used in the personal
mini fan.

...................................................................................................................................................

...................................................................................................................................................

...................................................................................................................................................

.............................................................................................................................................. [2]




© OCR 2023

, 3
(c) The personal mini fan is powered by plugging it in to a USB socket.

Explain one benefit to the user and one benefit to the manufacturer of designing the
personal mini fan to be powered from a USB socket.

Benefit to user ..........................................................................................................................

...................................................................................................................................................

...................................................................................................................................................

...................................................................................................................................................

Benefit to manufacturer ............................................................................................................

...................................................................................................................................................

...................................................................................................................................................

...................................................................................................................................................
[4]
