, Q1: You are required to compare the performance of Binary Phase Shift Keying (BPSK) to Differential
BPSK (DPSK) using Simulink. use the following simulation parameters:
Start time: 0.0
Stop time: infinity
Type: variable-step
Solver: discrete (no continuous states)
Max. step size: auto
a. (30 points) Construct the system shown in figure Q1 using Simulink modeling software with the
sampling period (symbol period) is 0.1s. Show a screenshot of your work.
