JLTV TEST B QUESTIONS AND ANSWERS ALREADY PASSED /
LATEST 2024/2025
1. Which is the only JLTV variant with a two-seat configuration?
A. GP
B. HGC
C. CCWC
D. UTL: D. UTL
2. Which of the following lights indicates that you will NOT be able to adjust the
ride height?
A. LVD
B. SUSPENSION ERROR
C. SPNS NOT LEVEL
D. CTIS FAULT: B. SUSPENSION ERROR
3. What are the benefits of the vehicle design using half shafts instead of straight
axles on the JLTV?
A. To account for angles produced by suspension movement.
B. To ensure that both wheels respond as one while driving off-road
C. Because straight axles cannot be driven off road
D. To allow for the transmission of energy from the differential to the transaxle-: A.
To account for angles produced by suspension movement.
4. What makes up a fording kit?: Exhaust stack Pre-Cleaner
5. List the four Central Tire Inflation System (CTS) terrain settings: HWY, CC,
MSS, EMER
6. Explain why the MUX panel switches need to be pressed and held for at least one
second: Prevents inadvertent bumps or taps from changing the lighting settings
7. List three benefits the DSDU provides to the driver: Possible answers include: It
provides maintenance levels (like fluids, pressure and temperature) without having to
look under the hood.
It shows real time pitch and roll.
It shows the status of the suspension level and allows the driver to adjust the suspension.
Allows the CTIS options
It displays real time data about the circuit breaker.
It displays the status of critical vehicle systems.
1/6
, 8. Match the JLTV controls with the callouts on the dashboard shown below.:
DSDU C
HVAC controls F
Parking brake A
Systems Control MUX panel B
Trailer Air Supply D
Transmission Shift Selector E
9. Which of the following is NOT part of JLTV Basic Issue Items (BIl)?
A. Suspension lockout braces
B. Tow bar
C. Wheel chocks
D. Hydraulic jack adaptor: B. Tow bar
10. When inventorying your BII, which of the following codes is NOT used to
annotate the form?
A. S-ServIceable
B. P-Present
C. M-Missing
D. U-Unserviceable: B. P-Present
11. When temperature reaches _______ you should use the arctic kit to assist you in
starting your vehicle: 25
12. What is the combined rating of using a snatch block with the winch?: 36,000 Ibs
13. List three post-check items vou inspect after driving the JLTV.: Possible
Answers: Lights and reflectors, safety devices, air tanks, fluids
14. A unique characteristic of the JLTV is using the______to verify fluids and
system checks.
A.CTIS
B.MFoCS
C.DSDU
D.CSDU: C.DSDU
2/6
