Z-51 Written Test Questions And Answers
Well Illustrated.
In a steam turbine, what is the function of a Kingsbury thrust bearing?
A) Maintain first stage steam pressure.
B) Compensate for coupling misalignment.
C) Adjust shaft torque at start up.
D) Maintain axial positioning of the rotor shaft. - correct answer. D) Maintain axial
positioning of the rotor shaft.
The ratio of actual pressure of water pressure in the atmosphere to the saturated
pressure of given temperature is
A) partial pressure.
B) relative humidity.
C) humidity effect.
D) absolute humidity. - correct answer.
The total amount of heat to be removed from the refrigerant in a condenser equals the
heat picked up in the
A) evaporator plus the heat of compression.
B) evaporator.
C) evaporator plus the heat of included non-condensable.
D) evaporator less the heat given up in the muffler. - correct answer.
When must the Fire Department be notified that a fire protection system is out of
service?
A) The manual pull alarm station in the lobby will be out of service for 4 hours.
B) Four sprinkler heads on a same floor of your building will be out of service for 2
hours.
C) The sprinkler system will be out of service on 1st and 2nd floors.
,D) The fire alarm system is out of service in the refrigerating system room for g hours. -
correct answer. C) The sprinkler system will be out of service on 1st and 2nd floors.
Hot work authorizations are issued by
A) a Responsible Person designated by the Building Owner.
B) a Building Department inspector.
C) a FDNY inspector.
D) the Building owner's insurance company. - correct answer. A) a Responsible
Person designated by the building owner.
Insecticidal fogging operations are hazardous because chemicals
A) are corrosive.
B) are water-reactive.
C) may be toxic.
D) are highly unstable. - correct answer. C) may be toxic.
What is a compressor safety head?
A) Rupture disc.
B) A pressure relief valve on the low side.
C) Cylinder head with a low pressure relief on the high side.
D) A spring on the valve plate. - correct answer.
The oil collected in an oil separator is generally
A) caused by an oil overcharge.
B) returned to the compressor.
C) filtered and returned to the compressor.
D) drained and replaced by fresh oil. - correct answer.
Where is emergency power not required according to code?
A) Fire pumps.
B) High rise elevators.
C) Egress illumination.
D) Data centers. - correct answer. D) Data centers.
Modern compressors usually seal the rotating shaft seal as it exits the compressor
housing a spring-loaded seal made of
A) low-friction plastic.
B) rubber.
C) metal or carbon.
D) graphite-loaded fiber. - correct answer.
, A technician shows up to service the fire alarm panel in your building. What COF
qualifications must he/she have?
A) A Q-01/Q-99 Certificate of Qualification holder who is designated by the building
owner.
B) A certified Fire Safety Director who is designated by the building owner.
C) A S-95 Certificate of Fitness holder who is employed by a FDNY certified company.
D) A S-97/S-98 Certificate of Fitness holder who is employed by a FDNY certified
company. - correct answer. D) A S-97/S-98 Certificate of Fitness holder who is
employed by a FDNY certified company.
Which statement is correct regarding a fusible plug on a condenser?
A) The melting point is marked on it.
B) Are not allowed by code.
C) Release refrigerant by pressure.
D) Can be back-seated. - correct answer.
In an office building, the display of cut natural trees (Christmas trees) is
A) never allowed.
B) allowed provided they are removed once they dry out.
C) always allowed.
D) allowed during the holiday season. - correct answer. A) never allowed.
Describe the equipment's function in the picture.
A) Control flow of refrigerant to the compressor.
B) Remove non-condensable from the condenser.
C) Relieve excess pressure from the condenser.
D) Relieve excess pressure from the evaporator. - correct answer. B) Remove non-
condensable from the condenser.
When the expansion valve is operating properly, the end of the evaporator will contain
A) only superheated vapor.
B) saturated liquid refrigerant
C) only vapor.
D) only liquid refrigerant. - correct answer. A) only superheated vapor.
How much extra refrigerant con be stored in a machine room?
A) 330 lbs.
B) The amount equal to the design pressure.
C) 20% above normal charge.
