NEIEP 600 Final Verified Questions And Answers With
2023/2024 Updates
, NEIEP 600 Final Verified Questions And Answers With
2023/2024 Updates
Refer to figure, If load resistance R2 is reduced by half, what happens to
the zener diode?
(Ans- Zener current will decrease
Refer to the figure, the zener diode is designed to breakdown at 6VDC. What is
the voltage drop across resistor 1, with a constant DC supply of 10 VDC?
(Ans- 4V
An elevators motor rotates at 1200 rpm at contract speed and is geared ata ratio of
40:1. If the motor turns 40 rpm the sheave turns 1 rpm. What is the actual speed of
the drive sheave in rpms?
(Ans- 30 rpm
Refer to the figure, for the comparator circuit shown, what will happen to the
output if the non inverting input goes more positive than the inverting input?
(Ans- The output will go to zero.
Refer to the figure, for the inverting op amp shown, what is the outputvoltage?
(Ans- 25 mv
