, Unit IV : Vehicle systems
• Chassis layout,
• Suspension system,
• Steering system, Front axle, Ackermann steering mechanism
• Braking system,
• Cooling system,
• Fuel injection system & fuel supply system MPFI & Diesel
a. State and explain any four systems of Two Wheeler. [ 6m]
b. What is chassis? Draw the layout of Chassis of vehicle. [6m]
c. What are the different layouts of vehicle. [9m]
d. Explain with neat sketch “Front Engine Rear Wheel Drive” (FERWD). [6m]
e. Explain with neat sketch “Articulated Vehicle Layout” [6m]
f. What is Suspension system of automobile vehicle? State its functions. [6m]
g. With neat sketch explain the Suspension system ( leaf spring arrangement) [4m]
h. Explain with neat sketch “Hydro-Gas Suspension System”. [6m]
i. Describe Steering System with sketch. [5m]
j. State the functions of Braking system. [ 4m]
k. Explain working of Mechanical Brake. [6m]
l. What is the necessity of cooling System? What are the different methods of it? [6m]
m. With neat diagram, explain cooling system used in four wheeler Engines. [6m]
1. Automobile Chassis :
chassis layouts : Concept of Chassis, Types of chassis layouts to be covered with arrangement
of different components on it .
• Chassis is a basic structure of vehicle. Chassis carry all parts of vehicles.
Automotive chassis is a skeletal frame on which various mechanical parts like
engine, tires, axle assemblies, brakes, steering etc. are bolted
1 of 23
Other Subjects: https://www.studymedia.in/fe/notes
, • Automobile chassis is usually made of light sheet metal. It provides strength needed
for supporting vehicular components and payload placed upon it.
• Automobile chassis helps keep an automobile rigid, stiff and unbending. Auto chassis
ensures low levels of noise, vibrations and harshness throughout the automobile.
• The frame is made of Box, Tubular channel or U-shaped sections ; which are welded or
riveted together.
Types of Chassis ( According to control )
• Backward control ( conventional chassis )
• Forward control
• Semi – forward control
Backward control ( conventional chassis)
• Here engine is usually mounted in front of driver’s seat. This offers advantage as safety
of driver in case of head collision.
• Driver’s front view is reduced as well as space utilization for pay load is also reduced.
Forward control chassis
• The engine is mounted completely inside driver’s cabin.
• Full utilization of space.
• Driver’s safety is reduced to large extent in case of head on collision with other vehicle.
Semi- forward control chassis
• Half engine fitted inside driver’s cabin.
• This chassis layout gives advantage good drivers safety and more space utilization.
Typical Layouts in Automobile :
1. Front Engine Rear Wheel Drive (FERWD)
2. Rear Engine Rear Wheel Drive ( RERWD)
3. Front Engine Front Wheel Drive (FEFWD)
4. All Wheel Drive ( AWD)
5. Articulated Vehicle Layout ( AVL)
2 of 23
