1. The rigid beam AC is supported by the 75 mm wide x 10 mm thick strut BD as shown below. If P = 3.0 kN, Determine the minimum required diameter (in mm) of the bolt at B if the allowable shearing stress is 50 MPa, 2. A hollow circular pole 300 mm in diameter, 6 mm thick, and 3 m high is fixed at the base. The pole is subjected to a torque T = 25 kN m and a lateral force H = 3 kN at the top. Modulus of rigidity G = 78 GPa and the allowable shear stress is 60 MPa. is subjected to a couple having a moment, M, as shown below. 4. The shear diagram of a 9 m beam is given below. TR = RE = EB = 3m.
