,Name: Class: Date:
Mod 01 Taking a Computer Apart and Putting it Back Together
1. You replace an internal drive that is only used to backup data on a computer. Before you
install the case cover, you power on the computer and observe the disk drive lights are not
blinking. You suspect it may not be receiving power, but cannot find the power supply tester.
How can you quickly verify whether power is being supplied to the disk drive?
a. Use a POST card
b. Replace the power supply
c. Run diagnostic software once the OS loads
d. Use a multimeter
ANSWER: d
FEEDBACK: a. Incorrect. A POST (power-on self-test) card is used to
troubleshoot problems that occur after you power on the
computer but before the operating system is loaded. The
replacement drive is only used to backup data so we can
infer that it does not contain the operating system. The
question does not indicate the computer did not boot
successfully so POST must have completed without errors.
b. Incorrect. Replacing the power supply may fix the problem
but it is not the best way to quickly verify whether power is
being supplied to the drive.
c. Incorrect. Running diagnostic software once the operating
system is up and running will not determine if there is power
being applied to the drive. If no power is being supplied, the
system will simply will not detect the hard drive.
d. Correct. You can use a multimeter to verify the appropriate
voltage level is detected on the connector used to supply
power to the drive.
POINTS: 1
QUESTION TYPE: Multiple Choice
HAS VARIABLES: False
LEARNING OBJECTIVES: WEST.A+.23.1.1 - Disassemble and reassemble a desktop computer
safely, and identify external ports and major components inside a
desktop. Describe how they connect and are compatible. Identify various
tools you will need as a computer hardware technician.
ACCREDITING STANDARDS: WEST.220-1001.23.3.4 - Given a scenario, select, install and configure
storage devices
TOPICS: Exploring a Desktop Computer
KEYWORDS: Bloom's: Analyze
DATE CREATED: 7/22/2022 8:00 PM
DATE MODIFIED: 7/22/2022 8:00 PM
2. A technician is building a custom gaming computer for a customer. In what order should the
technician install the main components?
a. power supply, drives, motherboard, cards
b. drives, motherboard, cards, power supply
c. motherboard, cards, power supply, drives
d. mother board, power supply, drives, and cards
ANSWER: a
Copyright Cengage Learning. Powered by Cognero. Page 1
,Name: Class: Date:
Mod 01 Taking a Computer Apart and Putting it Back Together
FEEDBACK: a. Correct. Since the motherboard and processor are the most
expensive components, if possible it is best to install the
motherboard just before installing the expansion cards to
prevent damage. For example, you would not want to drop a
disk drive or power supply on the motherboard while
installing those components.
b. Incorrect. In some cases, you may need to install the drives
before the motherboard, but if possible, it is best to install the
motherboard just before the expansion cards to prevent
accidental damage to the motherboard.
c. Incorrect. If possible, it is best to install the motherboard just
before the expansion cards to prevent accidental damage to
the motherboard.
d. Incorrect. If possible, it is best to install the motherboard just
before the expansion cards to prevent accidental damage to
the motherboard.
POINTS: 1
QUESTION TYPE: Multiple Choice
HAS VARIABLES: False
LEARNING OBJECTIVES: WEST.A+.23.1.1 - Disassemble and reassemble a desktop computer
safely, and identify external ports and major components inside a
desktop. Describe how they connect and are compatible. Identify various
tools you will need as a computer hardware technician.
ACCREDITING STANDARDS: WEST.220-1001.23.1.1 - Given a scenario, install and configure laptop
hardware and components
TOPICS: Exploring a Desktop Computer
KEYWORDS: Bloom's: Apply
DATE CREATED: 7/22/2022 8:00 PM
DATE MODIFIED: 7/22/2022 8:00 PM
3. An employee informs the help desk the laptop they are using cannot update the login
credentials when they plug it in to the company's wired network. Wireless connectivity is fine,
but the login credentials cannot be updated using Wi-Fi. What is a possible action the help desk
could take to troubleshoot the problem?
a. Replace the network card
b. Ping the loopback address
c. Use a loopback plug
d. Use a USB to RJ-45 dongle
ANSWER: c
FEEDBACK: a. Incorrect. The network port on a laptop is integrated into the
motherboard so the help desk would not try to replace the
network card.
b. Incorrect. Ping is used to verify network connectivity.
However, pinging the loopback address (127.0.0.1) is used to
verify the networking protocols are installed and working
properly on the laptop. It does not transmit any data so it will
not serve as an effective method to test the network port on
the laptop.
c. Correct. A loopback plug can be used to test whether the
network port on the laptop is working properly.
Copyright Cengage Learning. Powered by Cognero. Page 2
,Name: Class: Date:
Mod 01 Taking a Computer Apart and Putting it Back Together
d. Incorrect. A USB to RJ-45 dongle basically adds another
network port to the laptop through the USB port but in and of
itself it will not test the existing/original network port on the
laptop.
POINTS: 1
QUESTION TYPE: Multiple Choice
HAS VARIABLES: False
LEARNING OBJECTIVES: WEST.A+.23.1.2 - Disassemble and reassemble a laptop computer
safely, and identify external ports and slots and major internal
components. Understand special concerns when supporting and
maintaining laptops.
ACCREDITING STANDARDS: WEST.220-1001.23.2.8 - Given a scenario, use appropriate networking
tools
TOPICS: First Look at Laptop Components
KEYWORDS: Bloom's: Analyze
DATE CREATED: 7/22/2022 8:00 PM
DATE MODIFIED: 7/22/2022 8:00 PM
4. Which statement best describe when you would need to use a Thunderbolt 3 port as opposed to
a DisplayPort or an HDMI port?
a. When you need to transmit a digital and analog video signal on the same port and
cable
b. When you need to transmit video, audio, data, and power on the same port and cable
c. When the system is missing a DVI and/or VGA port to transmit video and audio
signals
d. When you do not have a DVI to VGA adapter to convert digital signals to an analog
format
ANSWER: b
FEEDBACK: a. Incorrect. Thunderbolt 3 does not natively transmit analog
signals, but it can be used to connect VGA displays with the
aid of an adapter.
b. Correct. Thunderbolt 3 can transmit video, audio, data and
power on the same port and cable. It can support up to six
peripheral devices simultaneously.
c. Incorrect. DVI can transmits digital and analog video. VGA
can only transmit analog video. Neither one can transmit
audio or power.
d. Incorrect. VGA and DVI only transmit video signals, no audio
or power. A DVI to VGA adapter is used to convert a digital
video signal to an analog video signal.
POINTS: 1
QUESTION TYPE: Multiple Choice
HAS VARIABLES: False
LEARNING OBJECTIVES: WEST.A+.23.1.1 - Disassemble and reassemble a desktop computer
safely, and identify external ports and major components inside a
desktop. Describe how they connect and are compatible. Identify various
tools you will need as a computer hardware technician.
ACCREDITING STANDARDS: WEST.220-1001.23.1.3 - Given a scenario, use appropriate laptop
Copyright Cengage Learning. Powered by Cognero. Page 3
,Name: Class: Date:
Mod 01 Taking a Computer Apart and Putting it Back Together
features
TOPICS: Exploring a Desktop Computer
KEYWORDS: Bloom's: Analyze
DATE CREATED: 7/22/2022 8:00 PM
DATE MODIFIED: 7/22/2022 8:00 PM
5. Alexa is asked to upgrade the memory on a desktop computer. Which component will she
replace?
a. SO-DIMM
b. SSD
c. Flash memory
d. DIMM
ANSWER: d
FEEDBACK: a. Incorrect. SO-DIMM is a small outline dual-inline memory
module. The RAM form factor used on laptop computers.
b. Incorrect. SSD is a solid-state drive. It provides persistent
(not temporary) storage to store the operating system,
program files, and user data.
c. Incorrect. Flash memory is the memory type used in, for
example, USB flash drives.
d. Correct. DIMM is a dual-inline memory module. It represents
the RAM form factor used on desktop computers to store
temporary data and instructions being processed by the
CPU. Once power is turned off, all information in RAM is lost.
If the system is powered off cleanly, the needed information
is written to (saved) on the hard drive.
POINTS: 1
QUESTION TYPE: Multiple Choice
HAS VARIABLES: False
LEARNING OBJECTIVES: WEST.A+.23.1.1 - Disassemble and reassemble a desktop computer
safely, and identify external ports and major components inside a
desktop. Describe how they connect and are compatible. Identify various
tools you will need as a computer hardware technician.
ACCREDITING STANDARDS: WEST.220-1001.23.3.2 - Identify common connector types
TOPICS: Exploring a Desktop Computer
KEYWORDS: Bloom's: Apply
DATE CREATED: 7/22/2022 8:00 PM
DATE MODIFIED: 7/22/2022 8:00 PM
6. You suspect your computer is overheating because your system sometimes restarts or turns off
by itself. At other times the 32 inch monitor turns blue, and the system remains unresponsive
until you manually restart it. What relatively quick measure can you take to try to fix the
problem?
a. Remove the existing CPU and install a new one
b. Replace the fan and heat sink assembly on the CPU
c. Use a can of compressed air to blow out the dust
Copyright Cengage Learning. Powered by Cognero. Page 4
,Name: Class: Date:
Mod 01 Taking a Computer Apart and Putting it Back Together
d. Move the laptop to a temperature controlled environment
ANSWER: c
FEEDBACK: a. Incorrect. Replacing the CPU may work, but it is not necessarily a relatively q
measure.
b. Incorrect. Replacing the fan/heat sink assembly on the CPU may fix the prob
not necessarily a relatively quick measure.
c. Correct. The buildup of dust inside a computer can cause the computer to ov
can of compressed air to gently blow out the dust inside the computer and ai
d. Incorrect. If the computer has a 32" monitor, it is not a laptop. Plus, moving it
temperature controlled environment does not address the root cause of the p
POINTS: 1
QUESTION TYPE: Multiple Choice
HAS VARIABLES: False
LEARNING OBJECTIVES: WEST.A+.23.1.1 - Disassemble and reassemble a desktop computer safely, and ide
and major components inside a desktop. Describe how they connect and are compat
various tools you will need as a computer hardware technician.
ACCREDITING STANDARDS: WEST.220-1001.23.1.1 - Given a scenario, install and configure laptop hardware an
TOPICS: Exploring a Desktop Computer
KEYWORDS: Bloom's: Analyze
DATE CREATED: 7/22/2022 8:00 PM
DATE MODIFIED: 7/22/2022 8:00 PM
7. The original P1 connector had 20 pins, why did the development of PCIe induce the adoption
of a 24-pin P1 connector?
a. PCIe slots are faster than the previous generation and requires more power
b. The four new PCIe slots each require one extra pin on the P1 connector
c. To provide an additional 12 volts to the PCIe slots required by graphics cards
d. ATX specification 1.1 supports PCIe and calls for additional power requirements
ANSWER: a
FEEDBACK: a. Correct. PCI Express (PCIe) slots are faster than PCI and
require additional power. The 24-pin or 20+4-pin P1
connector provide +12 volts, +5 volts, and +3.3 volts of
output.
b. Incorrect. Mother boards are not limited to four PCIe slots.
Some have less, some have more so the implied limitation is
not accurate.
c. Incorrect. The 24-pin P1 connector provides +12 volts, +5
volts, and +3.3 volts, not just 12 volts. In addition, PCIe slots
are not only for graphics cards. A variety of devices can be
installed in PCIe slots such as sound cards, wired and
wireless network cards, video capture cards, RAID controller
cards, etc.
d. Incorrect. ATX 1.1 does not support the additional power
requirements of PCIe and does not call for a 24-pin P1
connector; ATX 2.2 does.
POINTS: 1
QUESTION TYPE: Multiple Choice
HAS VARIABLES: False
Copyright Cengage Learning. Powered by Cognero. Page 5
,Name: Class: Date:
Mod 01 Taking a Computer Apart and Putting it Back Together
LEARNING OBJECTIVES: WEST.A+.23.1.1 - Disassemble and reassemble a desktop computer
safely, and identify external ports and major components inside a
desktop. Describe how they connect and are compatible. Identify various
tools you will need as a computer hardware technician.
ACCREDITING STANDARDS: WEST.220-1001.23.1.1 - Given a scenario, install and configure laptop
hardware and components
TOPICS: Exploring a Desktop Computer
KEYWORDS: Bloom's: Analyze
DATE CREATED: 7/22/2022 8:00 PM
DATE MODIFIED: 7/22/2022 8:00 PM
8. Your company sells hundreds of large storage disk arrays every year that can be configured
locally using a dedicated laptop. You travel between many customer sites providing maintenance
and support to these laptops. It is your responsibility to ensure you have the necessary FRUs as
you travel from site to site. At the very least, what type of FRUs will you keep on-hand?
a. DIMMs, monitor, keyboard, mouse, and wireless card
b. Port replicator, webcam, headphones, network cable
c. P1 connectors, SATA cables, video card, and a multimeter
d. Memory modules, hard drives, keyboards, and wireless card
ANSWER: d
FEEDBACK: a. Incorrect. Laptops do not use DIMMs (dual inline memory
modules), they use SO-DIMMs (small outline DIMMs). The
keyboard and wireless card are FRUs (field replaceable
units).
b. Incorrect. None of these devices are considered FRUs (field
replaceable units). The webcam is not considered an FRU as
it is typically built into the screen and cannot be easily
replaced compared to a traditional FRU.
c. Incorrect. Laptops do not use P1 connectors. SSDs on a
laptop typically slide into a connector so you would not be
replacing SATA cables as you do in a desktop. The video
card is integrated into the motherboard and not considered
an FRU. A multimeter is not an internal FRU device.
d. Correct. FRUs are field replaceable units. These are internal
devices that can be replaced in the field with relative ease if
they become defective.
POINTS: 1
QUESTION TYPE: Multiple Choice
HAS VARIABLES: False
LEARNING OBJECTIVES: WEST.A+.23.1.2 - Disassemble and reassemble a laptop computer
safely, and identify external ports and slots and major internal
components. Understand special concerns when supporting and
maintaining laptops.
ACCREDITING STANDARDS: WEST.220-1001.23.1.1 - Given a scenario, install and configure laptop
hardware and components
TOPICS: First Look at Laptop Components
KEYWORDS: Bloom's: Analyze
DATE CREATED: 7/22/2022 8:00 PM
DATE MODIFIED: 7/22/2022 8:00 PM
Copyright Cengage Learning. Powered by Cognero. Page 6
,Name: Class: Date:
Mod 01 Taking a Computer Apart and Putting it Back Together
9. Maria has a laptop with a motherboard that is beyond repair. She comes to your computer
repair shop and requests that you replace the motherboard. What are two of the most likely
responses you will give her?
a. Buy a new laptop because replacing it will be more cost-effective than repairing it.
b. You thank them for their business, tell them how much it will cost, and how long it
will take.
c. You assure the customer it is not the system board because they seldom go bad; you
will troubleshoot and fix it.
d. Your shop has made a conscious decision not to replace motherboards on laptops.
e. It will take a long time because laptop motherboards are not typically in stock.
ANSWER: a, d
FEEDBACK: a. Correct. Replacing the motherboard on a laptop can be time-
consuming and costly so this is not a recommended course
of action.
b. Incorrect. Unless you are very experienced replacing
motherboards in laptops, you don't know for sure how much it
will cost and how long it will take. You might end up losing
money in the process and not complete the task to the
customer's satisfaction.
c. Incorrect. You cannot make an absolute determination on
what is or is not the problem without some level of
troubleshooting. It is better not to give the customer what
could be a false sense of hope.
d. Correct. Choosing not to replace motherboards on laptops is
a reasonable policy to adopt because it is time-consuming
and costly.
e. Incorrect. Not in stock where, in your shop, or at the factory?
In either case, the process is time-consuming and costly.
Thus, it is best not to replace motherboards in laptops.
POINTS: 1
QUESTION TYPE: Multiple Response
HAS VARIABLES: False
LEARNING OBJECTIVES: WEST.A+.23.1.2 - Disassemble and reassemble a laptop computer
safely, and identify external ports and slots and major internal
components. Understand special concerns when supporting and
maintaining laptops.
ACCREDITING STANDARDS: WEST.220-1001.23.3.4 - Given a scenario, select, install and configure
storage devices
TOPICS: First Look at Laptop Components
KEYWORDS: Bloom's: Analyze
DATE CREATED: 7/22/2022 8:00 PM
DATE MODIFIED: 7/22/2022 8:00 PM
10. Which two statements are true about 4-pin 12 V, 8-pin 12 V, 6-pin PCIe, and 8-pin PCIe
connectors?
a. The 6-pin and 8-pin PCIe connectors do not provide 12 volts of output.
b. The 4-pin 12 V and 8-pin 12 V connectors provide auxiliary power to video cards.
Copyright Cengage Learning. Powered by Cognero. Page 7
, Name: Class: Date:
Mod 01 Taking a Computer Apart and Putting it Back Together
c. The 6-pin and 8-pin PCIe connectors provide auxiliary power to video cards.
d. The 4-pin 12 V and 8-pin 12 V connectors provide auxiliary power to the CPU.
e. The 6-pin and 8-pin PCIe connectors provide auxiliary power to the CPU.
ANSWER: c, d
FEEDBACK: a. Incorrect. All the connectors provide +12 volts of output. The 4-pin 12 V and
connectors provide auxiliary power to the processor. The 6 and 8-pin PCIe c
provide auxiliary power to high-end video cards using PCI Express.
b. Incorrect. The 4-pin 12 V and 8-pin 12 V connectors provide auxiliary power
not to graphic cards.
c. Correct. The 6-pin and 8-pin PCIe connectors provide auxiliary power to high
cards using PCI Express.
d. Correct. The 4-pin 12 V and 8-pin 12 V connectors are auxiliary system boar
used to provide an extra 12 V of output to the processor.
e. Incorrect. The 6-pin and 8-pin PCIe connectors provide auxiliary power to hig
graphics cards using PCI Express, not to the CPU.
POINTS: 1
QUESTION TYPE: Multiple Response
HAS VARIABLES: False
LEARNING OBJECTIVES: WEST.A+.23.1.1 - Disassemble and reassemble a desktop computer safely, and ide
and major components inside a desktop. Describe how they connect and are compat
various tools you will need as a computer hardware technician.
ACCREDITING STANDARDS: WEST.220-1001.23.1.1 - Given a scenario, install and configure laptop hardware an
TOPICS: Exploring a Desktop Computer
KEYWORDS: Bloom's: Analyze
DATE CREATED: 7/22/2022 8:00 PM
DATE MODIFIED: 7/22/2022 8:00 PM
11. A technician has determined that a laptop keyboard will need to be removed in order to
replace the laptop's CPU cooling fan.
Which of the following steps will most likely be required before the technician can remove the
keyboard from the laptop? (Select two.)
a. The keyboard backlight will need to be toggled off by using the appropriate Fn keys.
And another paragraph on the answer.
b. The keyboard cable(s) will need to be disconnected from the ZIF socket(s).
c. The keyboard cable will need to be disconnected from the mini-PCIe slot.
d. The keyboard bezel will need to be removed.
e. The technician will need to remove the display assembly and system board.
ANSWER: b, d
FEEDBACK: a. Incorrect. The keyboard backlight component is integrated
into the laptop keyboard that illuminates the keys. The laptop
will be powered off when the keyboard is removed, making
this choice irrelevant.
b. Correct. Typical laptop keyboards are connected to the
system board via one or more ribbon cables. The system
board end of the ribbon cable utilizes ZIF (zero insertion
force) sockets. These cables will need to be disconnected
prior to removal of the keyboard.
Copyright Cengage Learning. Powered by Cognero. Page 8
Technology Technical Support, 11th Edition Jean
Andrews
Notes
1- All Chapters are step by step.
2- We have shown you 10 pages.
3- The file contains all Appendix and Excel
sheet if it exists.
4- We have all what you need, we make
update at every time. There are many
new editions waiting you.
5- If you think you purchased the wrong file
You can contact us at every time, we can
replace it with true one.
Our email:
,Name: Class: Date:
Mod 01 Taking a Computer Apart and Putting it Back Together
1. You replace an internal drive that is only used to backup data on a computer. Before you
install the case cover, you power on the computer and observe the disk drive lights are not
blinking. You suspect it may not be receiving power, but cannot find the power supply tester.
How can you quickly verify whether power is being supplied to the disk drive?
a. Use a POST card
b. Replace the power supply
c. Run diagnostic software once the OS loads
d. Use a multimeter
ANSWER: d
FEEDBACK: a. Incorrect. A POST (power-on self-test) card is used to
troubleshoot problems that occur after you power on the
computer but before the operating system is loaded. The
replacement drive is only used to backup data so we can
infer that it does not contain the operating system. The
question does not indicate the computer did not boot
successfully so POST must have completed without errors.
b. Incorrect. Replacing the power supply may fix the problem
but it is not the best way to quickly verify whether power is
being supplied to the drive.
c. Incorrect. Running diagnostic software once the operating
system is up and running will not determine if there is power
being applied to the drive. If no power is being supplied, the
system will simply will not detect the hard drive.
d. Correct. You can use a multimeter to verify the appropriate
voltage level is detected on the connector used to supply
power to the drive.
POINTS: 1
QUESTION TYPE: Multiple Choice
HAS VARIABLES: False
LEARNING OBJECTIVES: WEST.A+.23.1.1 - Disassemble and reassemble a desktop computer
safely, and identify external ports and major components inside a
desktop. Describe how they connect and are compatible. Identify various
tools you will need as a computer hardware technician.
ACCREDITING STANDARDS: WEST.220-1001.23.3.4 - Given a scenario, select, install and configure
storage devices
TOPICS: Exploring a Desktop Computer
KEYWORDS: Bloom's: Analyze
DATE CREATED: 7/22/2022 8:00 PM
DATE MODIFIED: 7/22/2022 8:00 PM
2. A technician is building a custom gaming computer for a customer. In what order should the
technician install the main components?
a. power supply, drives, motherboard, cards
b. drives, motherboard, cards, power supply
c. motherboard, cards, power supply, drives
d. mother board, power supply, drives, and cards
ANSWER: a
Copyright Cengage Learning. Powered by Cognero. Page 1
,Name: Class: Date:
Mod 01 Taking a Computer Apart and Putting it Back Together
FEEDBACK: a. Correct. Since the motherboard and processor are the most
expensive components, if possible it is best to install the
motherboard just before installing the expansion cards to
prevent damage. For example, you would not want to drop a
disk drive or power supply on the motherboard while
installing those components.
b. Incorrect. In some cases, you may need to install the drives
before the motherboard, but if possible, it is best to install the
motherboard just before the expansion cards to prevent
accidental damage to the motherboard.
c. Incorrect. If possible, it is best to install the motherboard just
before the expansion cards to prevent accidental damage to
the motherboard.
d. Incorrect. If possible, it is best to install the motherboard just
before the expansion cards to prevent accidental damage to
the motherboard.
POINTS: 1
QUESTION TYPE: Multiple Choice
HAS VARIABLES: False
LEARNING OBJECTIVES: WEST.A+.23.1.1 - Disassemble and reassemble a desktop computer
safely, and identify external ports and major components inside a
desktop. Describe how they connect and are compatible. Identify various
tools you will need as a computer hardware technician.
ACCREDITING STANDARDS: WEST.220-1001.23.1.1 - Given a scenario, install and configure laptop
hardware and components
TOPICS: Exploring a Desktop Computer
KEYWORDS: Bloom's: Apply
DATE CREATED: 7/22/2022 8:00 PM
DATE MODIFIED: 7/22/2022 8:00 PM
3. An employee informs the help desk the laptop they are using cannot update the login
credentials when they plug it in to the company's wired network. Wireless connectivity is fine,
but the login credentials cannot be updated using Wi-Fi. What is a possible action the help desk
could take to troubleshoot the problem?
a. Replace the network card
b. Ping the loopback address
c. Use a loopback plug
d. Use a USB to RJ-45 dongle
ANSWER: c
FEEDBACK: a. Incorrect. The network port on a laptop is integrated into the
motherboard so the help desk would not try to replace the
network card.
b. Incorrect. Ping is used to verify network connectivity.
However, pinging the loopback address (127.0.0.1) is used to
verify the networking protocols are installed and working
properly on the laptop. It does not transmit any data so it will
not serve as an effective method to test the network port on
the laptop.
c. Correct. A loopback plug can be used to test whether the
network port on the laptop is working properly.
Copyright Cengage Learning. Powered by Cognero. Page 2
,Name: Class: Date:
Mod 01 Taking a Computer Apart and Putting it Back Together
d. Incorrect. A USB to RJ-45 dongle basically adds another
network port to the laptop through the USB port but in and of
itself it will not test the existing/original network port on the
laptop.
POINTS: 1
QUESTION TYPE: Multiple Choice
HAS VARIABLES: False
LEARNING OBJECTIVES: WEST.A+.23.1.2 - Disassemble and reassemble a laptop computer
safely, and identify external ports and slots and major internal
components. Understand special concerns when supporting and
maintaining laptops.
ACCREDITING STANDARDS: WEST.220-1001.23.2.8 - Given a scenario, use appropriate networking
tools
TOPICS: First Look at Laptop Components
KEYWORDS: Bloom's: Analyze
DATE CREATED: 7/22/2022 8:00 PM
DATE MODIFIED: 7/22/2022 8:00 PM
4. Which statement best describe when you would need to use a Thunderbolt 3 port as opposed to
a DisplayPort or an HDMI port?
a. When you need to transmit a digital and analog video signal on the same port and
cable
b. When you need to transmit video, audio, data, and power on the same port and cable
c. When the system is missing a DVI and/or VGA port to transmit video and audio
signals
d. When you do not have a DVI to VGA adapter to convert digital signals to an analog
format
ANSWER: b
FEEDBACK: a. Incorrect. Thunderbolt 3 does not natively transmit analog
signals, but it can be used to connect VGA displays with the
aid of an adapter.
b. Correct. Thunderbolt 3 can transmit video, audio, data and
power on the same port and cable. It can support up to six
peripheral devices simultaneously.
c. Incorrect. DVI can transmits digital and analog video. VGA
can only transmit analog video. Neither one can transmit
audio or power.
d. Incorrect. VGA and DVI only transmit video signals, no audio
or power. A DVI to VGA adapter is used to convert a digital
video signal to an analog video signal.
POINTS: 1
QUESTION TYPE: Multiple Choice
HAS VARIABLES: False
LEARNING OBJECTIVES: WEST.A+.23.1.1 - Disassemble and reassemble a desktop computer
safely, and identify external ports and major components inside a
desktop. Describe how they connect and are compatible. Identify various
tools you will need as a computer hardware technician.
ACCREDITING STANDARDS: WEST.220-1001.23.1.3 - Given a scenario, use appropriate laptop
Copyright Cengage Learning. Powered by Cognero. Page 3
,Name: Class: Date:
Mod 01 Taking a Computer Apart and Putting it Back Together
features
TOPICS: Exploring a Desktop Computer
KEYWORDS: Bloom's: Analyze
DATE CREATED: 7/22/2022 8:00 PM
DATE MODIFIED: 7/22/2022 8:00 PM
5. Alexa is asked to upgrade the memory on a desktop computer. Which component will she
replace?
a. SO-DIMM
b. SSD
c. Flash memory
d. DIMM
ANSWER: d
FEEDBACK: a. Incorrect. SO-DIMM is a small outline dual-inline memory
module. The RAM form factor used on laptop computers.
b. Incorrect. SSD is a solid-state drive. It provides persistent
(not temporary) storage to store the operating system,
program files, and user data.
c. Incorrect. Flash memory is the memory type used in, for
example, USB flash drives.
d. Correct. DIMM is a dual-inline memory module. It represents
the RAM form factor used on desktop computers to store
temporary data and instructions being processed by the
CPU. Once power is turned off, all information in RAM is lost.
If the system is powered off cleanly, the needed information
is written to (saved) on the hard drive.
POINTS: 1
QUESTION TYPE: Multiple Choice
HAS VARIABLES: False
LEARNING OBJECTIVES: WEST.A+.23.1.1 - Disassemble and reassemble a desktop computer
safely, and identify external ports and major components inside a
desktop. Describe how they connect and are compatible. Identify various
tools you will need as a computer hardware technician.
ACCREDITING STANDARDS: WEST.220-1001.23.3.2 - Identify common connector types
TOPICS: Exploring a Desktop Computer
KEYWORDS: Bloom's: Apply
DATE CREATED: 7/22/2022 8:00 PM
DATE MODIFIED: 7/22/2022 8:00 PM
6. You suspect your computer is overheating because your system sometimes restarts or turns off
by itself. At other times the 32 inch monitor turns blue, and the system remains unresponsive
until you manually restart it. What relatively quick measure can you take to try to fix the
problem?
a. Remove the existing CPU and install a new one
b. Replace the fan and heat sink assembly on the CPU
c. Use a can of compressed air to blow out the dust
Copyright Cengage Learning. Powered by Cognero. Page 4
,Name: Class: Date:
Mod 01 Taking a Computer Apart and Putting it Back Together
d. Move the laptop to a temperature controlled environment
ANSWER: c
FEEDBACK: a. Incorrect. Replacing the CPU may work, but it is not necessarily a relatively q
measure.
b. Incorrect. Replacing the fan/heat sink assembly on the CPU may fix the prob
not necessarily a relatively quick measure.
c. Correct. The buildup of dust inside a computer can cause the computer to ov
can of compressed air to gently blow out the dust inside the computer and ai
d. Incorrect. If the computer has a 32" monitor, it is not a laptop. Plus, moving it
temperature controlled environment does not address the root cause of the p
POINTS: 1
QUESTION TYPE: Multiple Choice
HAS VARIABLES: False
LEARNING OBJECTIVES: WEST.A+.23.1.1 - Disassemble and reassemble a desktop computer safely, and ide
and major components inside a desktop. Describe how they connect and are compat
various tools you will need as a computer hardware technician.
ACCREDITING STANDARDS: WEST.220-1001.23.1.1 - Given a scenario, install and configure laptop hardware an
TOPICS: Exploring a Desktop Computer
KEYWORDS: Bloom's: Analyze
DATE CREATED: 7/22/2022 8:00 PM
DATE MODIFIED: 7/22/2022 8:00 PM
7. The original P1 connector had 20 pins, why did the development of PCIe induce the adoption
of a 24-pin P1 connector?
a. PCIe slots are faster than the previous generation and requires more power
b. The four new PCIe slots each require one extra pin on the P1 connector
c. To provide an additional 12 volts to the PCIe slots required by graphics cards
d. ATX specification 1.1 supports PCIe and calls for additional power requirements
ANSWER: a
FEEDBACK: a. Correct. PCI Express (PCIe) slots are faster than PCI and
require additional power. The 24-pin or 20+4-pin P1
connector provide +12 volts, +5 volts, and +3.3 volts of
output.
b. Incorrect. Mother boards are not limited to four PCIe slots.
Some have less, some have more so the implied limitation is
not accurate.
c. Incorrect. The 24-pin P1 connector provides +12 volts, +5
volts, and +3.3 volts, not just 12 volts. In addition, PCIe slots
are not only for graphics cards. A variety of devices can be
installed in PCIe slots such as sound cards, wired and
wireless network cards, video capture cards, RAID controller
cards, etc.
d. Incorrect. ATX 1.1 does not support the additional power
requirements of PCIe and does not call for a 24-pin P1
connector; ATX 2.2 does.
POINTS: 1
QUESTION TYPE: Multiple Choice
HAS VARIABLES: False
Copyright Cengage Learning. Powered by Cognero. Page 5
,Name: Class: Date:
Mod 01 Taking a Computer Apart and Putting it Back Together
LEARNING OBJECTIVES: WEST.A+.23.1.1 - Disassemble and reassemble a desktop computer
safely, and identify external ports and major components inside a
desktop. Describe how they connect and are compatible. Identify various
tools you will need as a computer hardware technician.
ACCREDITING STANDARDS: WEST.220-1001.23.1.1 - Given a scenario, install and configure laptop
hardware and components
TOPICS: Exploring a Desktop Computer
KEYWORDS: Bloom's: Analyze
DATE CREATED: 7/22/2022 8:00 PM
DATE MODIFIED: 7/22/2022 8:00 PM
8. Your company sells hundreds of large storage disk arrays every year that can be configured
locally using a dedicated laptop. You travel between many customer sites providing maintenance
and support to these laptops. It is your responsibility to ensure you have the necessary FRUs as
you travel from site to site. At the very least, what type of FRUs will you keep on-hand?
a. DIMMs, monitor, keyboard, mouse, and wireless card
b. Port replicator, webcam, headphones, network cable
c. P1 connectors, SATA cables, video card, and a multimeter
d. Memory modules, hard drives, keyboards, and wireless card
ANSWER: d
FEEDBACK: a. Incorrect. Laptops do not use DIMMs (dual inline memory
modules), they use SO-DIMMs (small outline DIMMs). The
keyboard and wireless card are FRUs (field replaceable
units).
b. Incorrect. None of these devices are considered FRUs (field
replaceable units). The webcam is not considered an FRU as
it is typically built into the screen and cannot be easily
replaced compared to a traditional FRU.
c. Incorrect. Laptops do not use P1 connectors. SSDs on a
laptop typically slide into a connector so you would not be
replacing SATA cables as you do in a desktop. The video
card is integrated into the motherboard and not considered
an FRU. A multimeter is not an internal FRU device.
d. Correct. FRUs are field replaceable units. These are internal
devices that can be replaced in the field with relative ease if
they become defective.
POINTS: 1
QUESTION TYPE: Multiple Choice
HAS VARIABLES: False
LEARNING OBJECTIVES: WEST.A+.23.1.2 - Disassemble and reassemble a laptop computer
safely, and identify external ports and slots and major internal
components. Understand special concerns when supporting and
maintaining laptops.
ACCREDITING STANDARDS: WEST.220-1001.23.1.1 - Given a scenario, install and configure laptop
hardware and components
TOPICS: First Look at Laptop Components
KEYWORDS: Bloom's: Analyze
DATE CREATED: 7/22/2022 8:00 PM
DATE MODIFIED: 7/22/2022 8:00 PM
Copyright Cengage Learning. Powered by Cognero. Page 6
,Name: Class: Date:
Mod 01 Taking a Computer Apart and Putting it Back Together
9. Maria has a laptop with a motherboard that is beyond repair. She comes to your computer
repair shop and requests that you replace the motherboard. What are two of the most likely
responses you will give her?
a. Buy a new laptop because replacing it will be more cost-effective than repairing it.
b. You thank them for their business, tell them how much it will cost, and how long it
will take.
c. You assure the customer it is not the system board because they seldom go bad; you
will troubleshoot and fix it.
d. Your shop has made a conscious decision not to replace motherboards on laptops.
e. It will take a long time because laptop motherboards are not typically in stock.
ANSWER: a, d
FEEDBACK: a. Correct. Replacing the motherboard on a laptop can be time-
consuming and costly so this is not a recommended course
of action.
b. Incorrect. Unless you are very experienced replacing
motherboards in laptops, you don't know for sure how much it
will cost and how long it will take. You might end up losing
money in the process and not complete the task to the
customer's satisfaction.
c. Incorrect. You cannot make an absolute determination on
what is or is not the problem without some level of
troubleshooting. It is better not to give the customer what
could be a false sense of hope.
d. Correct. Choosing not to replace motherboards on laptops is
a reasonable policy to adopt because it is time-consuming
and costly.
e. Incorrect. Not in stock where, in your shop, or at the factory?
In either case, the process is time-consuming and costly.
Thus, it is best not to replace motherboards in laptops.
POINTS: 1
QUESTION TYPE: Multiple Response
HAS VARIABLES: False
LEARNING OBJECTIVES: WEST.A+.23.1.2 - Disassemble and reassemble a laptop computer
safely, and identify external ports and slots and major internal
components. Understand special concerns when supporting and
maintaining laptops.
ACCREDITING STANDARDS: WEST.220-1001.23.3.4 - Given a scenario, select, install and configure
storage devices
TOPICS: First Look at Laptop Components
KEYWORDS: Bloom's: Analyze
DATE CREATED: 7/22/2022 8:00 PM
DATE MODIFIED: 7/22/2022 8:00 PM
10. Which two statements are true about 4-pin 12 V, 8-pin 12 V, 6-pin PCIe, and 8-pin PCIe
connectors?
a. The 6-pin and 8-pin PCIe connectors do not provide 12 volts of output.
b. The 4-pin 12 V and 8-pin 12 V connectors provide auxiliary power to video cards.
Copyright Cengage Learning. Powered by Cognero. Page 7
, Name: Class: Date:
Mod 01 Taking a Computer Apart and Putting it Back Together
c. The 6-pin and 8-pin PCIe connectors provide auxiliary power to video cards.
d. The 4-pin 12 V and 8-pin 12 V connectors provide auxiliary power to the CPU.
e. The 6-pin and 8-pin PCIe connectors provide auxiliary power to the CPU.
ANSWER: c, d
FEEDBACK: a. Incorrect. All the connectors provide +12 volts of output. The 4-pin 12 V and
connectors provide auxiliary power to the processor. The 6 and 8-pin PCIe c
provide auxiliary power to high-end video cards using PCI Express.
b. Incorrect. The 4-pin 12 V and 8-pin 12 V connectors provide auxiliary power
not to graphic cards.
c. Correct. The 6-pin and 8-pin PCIe connectors provide auxiliary power to high
cards using PCI Express.
d. Correct. The 4-pin 12 V and 8-pin 12 V connectors are auxiliary system boar
used to provide an extra 12 V of output to the processor.
e. Incorrect. The 6-pin and 8-pin PCIe connectors provide auxiliary power to hig
graphics cards using PCI Express, not to the CPU.
POINTS: 1
QUESTION TYPE: Multiple Response
HAS VARIABLES: False
LEARNING OBJECTIVES: WEST.A+.23.1.1 - Disassemble and reassemble a desktop computer safely, and ide
and major components inside a desktop. Describe how they connect and are compat
various tools you will need as a computer hardware technician.
ACCREDITING STANDARDS: WEST.220-1001.23.1.1 - Given a scenario, install and configure laptop hardware an
TOPICS: Exploring a Desktop Computer
KEYWORDS: Bloom's: Analyze
DATE CREATED: 7/22/2022 8:00 PM
DATE MODIFIED: 7/22/2022 8:00 PM
11. A technician has determined that a laptop keyboard will need to be removed in order to
replace the laptop's CPU cooling fan.
Which of the following steps will most likely be required before the technician can remove the
keyboard from the laptop? (Select two.)
a. The keyboard backlight will need to be toggled off by using the appropriate Fn keys.
And another paragraph on the answer.
b. The keyboard cable(s) will need to be disconnected from the ZIF socket(s).
c. The keyboard cable will need to be disconnected from the mini-PCIe slot.
d. The keyboard bezel will need to be removed.
e. The technician will need to remove the display assembly and system board.
ANSWER: b, d
FEEDBACK: a. Incorrect. The keyboard backlight component is integrated
into the laptop keyboard that illuminates the keys. The laptop
will be powered off when the keyboard is removed, making
this choice irrelevant.
b. Correct. Typical laptop keyboards are connected to the
system board via one or more ribbon cables. The system
board end of the ribbon cable utilizes ZIF (zero insertion
force) sockets. These cables will need to be disconnected
prior to removal of the keyboard.
Copyright Cengage Learning. Powered by Cognero. Page 8
