CDW110 Exam Questions With 100%
Correct Answers | Verified | Latest
Update
,CHAPTER 1-Caboodle Console - Correct Answer-The Caboodle Console is a web application housed on the
Caboodle server. It includes the following:
Dictionary
Dictionary Editor
Executions Work
Queue
Configuration
CHAPTER 1-Data Warehouse - Correct Answer-In a data warehouse, multiple sources may load data
pertaining to a single entity. This means that more than one package may populate a given row in a
Caboodle table. As a result, there may be multiple business key values associated with a single entity in
a Caboodle table.
CHAPTER 1-ETL - Correct Answer-Extract, Transform, Load
CHAPTER 1-SSIS Package - Correct Answer-The architecture of Caboodle includes a staging database
and a reporting database. Data is extracted from source systems (like Clarity), transformed in the
staging database, and presented for users in the reporting database. This movement of data is realized
via a set of SQL Server Integration Services (SSIS) packages.
CHAPTER 1-Data Lineage - Correct Answer-Generally, data lineage refers to the process of identifying
the source of a specific piece of information. In Caboodle, data lineage is defined at the package level.
CHAPTER 1-Star Schema - Correct Answer-The standard schema for a dimensional data model.
The name refers to the image of a fact table surrounded by many linked dimension tables, which
loosely resembles a star.
The Caboodle data model structure is based on a "star schema" where one central fact table will join
to many associated lookup or dimension tables. This structure provides the foundation of the
Caboodle data model.
CHAPTER 1-DMC - Correct Answer-DATA MODEL COMPONENT
No table in Caboodle "stands alone." Each is considered part of a Data Model Component, which refers
to the collection of metadata tables that support the ETL process and reporting views stored in the
FullAccess schema.
Each DMC gets a type. Strict table naming conventions are followed in Caboodle, so that a table's suffix
provides information about its structure and purpose.
, These suffixes are:
· Dim for dimensions (e.g. PatientDim)
· Fact for facts (e.g. EncounterFact)
· Bridge for bridges (e.g. DiagnosisBridge)
· DataMart for data marts (e.g. HospitalReadmissionDataMart)
· AttributeValueDim for EAV tables (e.g. PatientAttributeValueDim)
· X for custom tables (e.g. CustomFactX)
CHAPTER 1-Staging Database - Correct Answer-The Caboodle database into which records are loaded
by SSIS packages and stored procedures.
CHAPTER 1-Reporting Database - Correct Answer-The architecture of Caboodle includes a staging
database and a reporting database. Data is extracted from source systems (like Clarity), transformed in
the staging database, and presented for users in the reporting database. This movement of data is
realized via a set of SQL Server Integration Services (SSIS)
packages.
CHAPTER 1-Dbo Schema - Correct Answer-STAGING DATABASE Import tables and
Mapping tables live here. This is
primarily used by administrators for moving data into Caboodle.
REPORTING DATABASE
The dbo schema stores reporting data and acts as the
data source for SlicerDicer. The Caboodle Dictionary reflects the contents of the dbo schema.
CHAPTER 1-FullAccess Schema - Correct Answer-STAGING DATABASE The FullAccess
schema does not exist on the Staging database.
REPORTING DATABASE
The FullAccess schema houses views that simplify reporting. FullAccess should be your default schema when
reporting.
CHAPTER 1-Identify key characteristics of the dimensional data model - Correct Answer-
MADE for report writers.
· Simpler and more intuitive.
· Easily extensible.
· More performant..
CHAPTER 1-Identify the benefits of the dimensional data model? - Correct Answer-It centralizes its
structure around more flexible fact and dimension tables, and the joins between these are more
intuitive.
CHAPTER 1-Identify documentation resources for reporting out of Caboodle - Correct Answer-
Correct Answers | Verified | Latest
Update
,CHAPTER 1-Caboodle Console - Correct Answer-The Caboodle Console is a web application housed on the
Caboodle server. It includes the following:
Dictionary
Dictionary Editor
Executions Work
Queue
Configuration
CHAPTER 1-Data Warehouse - Correct Answer-In a data warehouse, multiple sources may load data
pertaining to a single entity. This means that more than one package may populate a given row in a
Caboodle table. As a result, there may be multiple business key values associated with a single entity in
a Caboodle table.
CHAPTER 1-ETL - Correct Answer-Extract, Transform, Load
CHAPTER 1-SSIS Package - Correct Answer-The architecture of Caboodle includes a staging database
and a reporting database. Data is extracted from source systems (like Clarity), transformed in the
staging database, and presented for users in the reporting database. This movement of data is realized
via a set of SQL Server Integration Services (SSIS) packages.
CHAPTER 1-Data Lineage - Correct Answer-Generally, data lineage refers to the process of identifying
the source of a specific piece of information. In Caboodle, data lineage is defined at the package level.
CHAPTER 1-Star Schema - Correct Answer-The standard schema for a dimensional data model.
The name refers to the image of a fact table surrounded by many linked dimension tables, which
loosely resembles a star.
The Caboodle data model structure is based on a "star schema" where one central fact table will join
to many associated lookup or dimension tables. This structure provides the foundation of the
Caboodle data model.
CHAPTER 1-DMC - Correct Answer-DATA MODEL COMPONENT
No table in Caboodle "stands alone." Each is considered part of a Data Model Component, which refers
to the collection of metadata tables that support the ETL process and reporting views stored in the
FullAccess schema.
Each DMC gets a type. Strict table naming conventions are followed in Caboodle, so that a table's suffix
provides information about its structure and purpose.
, These suffixes are:
· Dim for dimensions (e.g. PatientDim)
· Fact for facts (e.g. EncounterFact)
· Bridge for bridges (e.g. DiagnosisBridge)
· DataMart for data marts (e.g. HospitalReadmissionDataMart)
· AttributeValueDim for EAV tables (e.g. PatientAttributeValueDim)
· X for custom tables (e.g. CustomFactX)
CHAPTER 1-Staging Database - Correct Answer-The Caboodle database into which records are loaded
by SSIS packages and stored procedures.
CHAPTER 1-Reporting Database - Correct Answer-The architecture of Caboodle includes a staging
database and a reporting database. Data is extracted from source systems (like Clarity), transformed in
the staging database, and presented for users in the reporting database. This movement of data is
realized via a set of SQL Server Integration Services (SSIS)
packages.
CHAPTER 1-Dbo Schema - Correct Answer-STAGING DATABASE Import tables and
Mapping tables live here. This is
primarily used by administrators for moving data into Caboodle.
REPORTING DATABASE
The dbo schema stores reporting data and acts as the
data source for SlicerDicer. The Caboodle Dictionary reflects the contents of the dbo schema.
CHAPTER 1-FullAccess Schema - Correct Answer-STAGING DATABASE The FullAccess
schema does not exist on the Staging database.
REPORTING DATABASE
The FullAccess schema houses views that simplify reporting. FullAccess should be your default schema when
reporting.
CHAPTER 1-Identify key characteristics of the dimensional data model - Correct Answer-
MADE for report writers.
· Simpler and more intuitive.
· Easily extensible.
· More performant..
CHAPTER 1-Identify the benefits of the dimensional data model? - Correct Answer-It centralizes its
structure around more flexible fact and dimension tables, and the joins between these are more
intuitive.
CHAPTER 1-Identify documentation resources for reporting out of Caboodle - Correct Answer-
