POSTAL AUTOMOTIVE TECHNICIAN EXAM 944 WITH ACTUAL EXAM
QUESTIONS AND 100% CORRECT ANSWERS WITH RATIONALES LATEST
(BRAND NEW!!)
Question 1
The vibration damper on an auto engine is fastened to the:
A) Camshaft
B) Flywheel
C) Crankshaft
D) Connecting rod
Correct Answer: C) Crankshaft
Rationale: The vibration damper (or harmonic balancer) is mounted on the front of the
crankshaft to absorb torsional vibrations and harmonics produced during engine
operation, which could otherwise cause the crankshaft to fracture.
Question 2
Most small gasoline engines, such as those in lawnmowers, use which type of ignition system?
A) Distributor-based
B) Distributorless (DIS)
C) Magneto
D) Coil-on-plug (COP)
Correct Answer: C) Magneto
Rationale: A magneto is a self-contained ignition system that uses permanent magnets and a
coil to generate its own electrical current, eliminating the need for a battery or external
power source. This makes it ideal for simple, small engines.
Question 3
Carburetor icing occurs most often on:
A) Cold, dry days
B) Hot, dry days
C) Cool, damp days
D) Hot, humid days
Correct Answer: C) Cool, damp days
Rationale: As fuel vaporizes in the carburetor's venturi, it causes a significant drop in
,temperature. On a cool, humid day, this can cause the moisture in the air to freeze, forming
ice that can block the throttle plate and jets, causing the engine to stall.
Question 4
What is the function of the float in a carburetor?
A) To mix the fuel with air.
B) To close the needle valve and maintain the correct fuel level in the float bowl.
C) To open and close the choke plate.
D) To control the engine's idle speed.
Correct Answer: B) To close the needle valve and maintain the correct fuel level in the float
bowl.
Rationale: The float rises and falls with the level of gasoline in the float bowl. As the bowl
fills, the float rises and pushes a needle valve closed, stopping the flow of fuel from the
pump. This maintains a constant fuel level for the carburetor jets.
Question 5
To improve stability and reduce body roll when a vehicle is cornering, manufacturers added a
device called a:
A) Torsion bar
B) Strut bar
C) Stabilizer bar (sway bar)
D) Tie rod
Correct Answer: C) Stabilizer bar (sway bar)
Rationale: A stabilizer bar is a type of spring that connects the left and right sides of the
suspension. During a turn, it resists the vehicle's tendency to lean or "roll," keeping the
body more level and improving tire contact with the road.
Question 6
Adjusting the length of the tie rods on a car will primarily affect which wheel alignment angle?
A) Caster
B) Camber
C) Steering axis inclination
D) Toe-in
,Correct Answer: D) Toe-in
Rationale: Tie rods connect the steering rack (or center link) to the steering knuckles at
each wheel. Lengthening or shortening the tie rods pushes or pulls the front of the wheels,
directly adjusting the toe-in or toe-out angle.
Question 7
A restriction in the exhaust system, such as a clogged catalytic converter, would be indicated on
a vacuum gauge by a:
A) Steady and normal reading.
B) Fluctuating needle at all speeds.
C) Gradual decrease in the reading at a steady RPM.
D) Very high reading at idle.
Correct Answer: C) Gradual decrease in the reading at a steady RPM.
Rationale: An exhaust restriction creates backpressure, which prevents the cylinders from
expelling all of their exhaust gases. This reduces the engine's ability to draw in a fresh air-
fuel mixture, causing the intake manifold vacuum to slowly drop as the engine runs at a
steady speed above idle.
Question 8
Disc brakes have a distinct advantage over conventional drum brakes because they:
A) Are self-adjusting.
B) Fade less when they get hot.
C) Have a self-energizing effect.
D) Are less expensive to manufacture.
Correct Answer: B) Fade less when they get hot.
Rationale: The open design of a disc brake rotor allows it to dissipate heat much more
effectively than an enclosed drum brake. This reduces "brake fade," which is the loss of
braking effectiveness caused by excessive heat buildup.
Question 9
In a diesel engine, how is the fuel ignited?
A) By a spark plug
B) By a glow plug
, C) By the heat of high compression
D) By the catalytic converter
Correct Answer: C) By the heat of high compression
Rationale: Diesel engines do not have spark plugs. They have very high compression ratios,
which heat the air in the cylinder to a temperature high enough to ignite the fuel as soon as
it is injected.
Question 10
Engine ignition timing is generally set by using a:
A) Dwell meter
B) Vacuum gauge
C) Compression tester
D) Strobe light (timing light)
Correct Answer: D) Strobe light (timing light)
Rationale: A timing light is connected to the #1 spark plug wire. It flashes each time the plug
fires, making the timing marks on the crankshaft pulley appear to stand still, allowing the
technician to see if the spark is occurring at the correct time relative to the piston's
position.
Question 11
If an engine operates at part throttle for long periods, leading to incomplete combustion, what is
the likely effect on the spark plugs?
A) The electrodes will wear out quickly.
B) The spark plugs will become covered with carbon.
C) The ceramic insulator will crack.
D) The spark plugs will become blistered and white.
Correct Answer: B) The spark plugs will become covered with carbon.
Rationale: Long periods of low-speed, light-load operation can cause the spark plugs to run
too cool to burn off carbon deposits. This carbon fouling can create a path for the spark to
short-circuit, causing misfires.
Question 12
What is a common symptom of leaking intake valve guides?
