LIEBHERR DEDICATED PILE DRIVER LOAD CHART MANUAL
NEWEST VERSION -2025/2026- 100+ QUESTIONS AND
VERIFIED ANSWERS 100% CORRECT GUARANTEED SUCCESS
Liability
Legal responsibility for damages or loss.
Express Written Permission
Explicit consent required for reproduction of materials.
Admiralty Law
Legal jurisdiction over maritime matters and navigation.
Perpetuity
State of lasting indefinitely without end.
No Warranty
Disclaimer stating no guarantees on information accuracy.
Testing Purposes Only
Indicates materials are not for operational use.
Manufacturer's Charts
Original load charts provided by equipment manufacturers.
Excerpts
Selected portions of the load chart included in manual.
Public Service
Publication aimed at improving industry safety standards.
, 2
Written Permission
Authorization required to reproduce copyrighted materials.
User's Sole Risk
Responsibility for use lies entirely with the user.
Clarifying Notes
Additional explanations accompanying excerpts in the manual.
Candidate Handbook
Guide for individuals preparing for certification exams.
Equipment Operation
Practical use of machinery in construction or lifting.
Public Safety
Protection of the general public from hazards.
Cooperation
Collaboration between NCCCO and manufacturers for publication.
Rev 12/16
Revision date indicating last update of the document.
Email Contact
Provided method for inquiries regarding the manual.
Hammer weight
Maximum weight of hammer: 12789 lbs.
Leader position
Leader must be vertical for operation.
Max travel speed
, 3
0.5 km/h on firm ground only.
Max swing speed
1 rpm when lifting loads.
Ground pressure
Pressure under chain with 900mm grousers.
Auxiliary winch load
No load allowed on auxiliary winch.
Minimum radius
Leader must have minimum radius and vertical.
Pile shaft position
Must be 2ft in front of leader.
Dynamic effects
No dynamic effects permitted during operation.
Counterweight requirement
13227 lbs rear counterweight required.
Ground conditions
Ground must be firm and level.
Travel condition
Uppercarriage must be parallel to undercarriage.
Lateral load
Max lateral load: 74.78 PSI.
Diagonal load
Max diagonal load: 76.71 PSI.
, 4
Front load
Max front load: 100.03 PSI.
Stability calculation
Applies when hammer and leader are lowest.
Ground pressure calculation
Calculated to middle plane of the machine.
Boom angle
Various angles from 72.0° to 42.0°.
Max pile weight
Maximum pile weight varies by conditions.
Inclination angle
Various angles specified for lateral stability.
Operating caution
Extreme caution required during machine operation.
Formation level
Lower edge of pile max. 1.6ft above level.
Drilling drive
Must be mounted for stability calculations.
Pile Weight
Weight of material in pounds.
Max. Pile Weight
Maximum allowable weight for a pile.
Weight Value
