,CHAPTER 1: Understanding Cardiac Dysrhythmias
What are Dysrhythmias?
Dysrhythmias (or arrhythmias) are abnormal rhythms of the heart caused by
disturbances in impulse formation or conduction. They can be harmless or life-
threatening. They can:
1. Reduce cardiac output
2. Cause hypotension, syncope, chest pain, or cardiac arrest
3. Range from benign to life-threatening
👉 Exam Focus:
1. Identify rhythm on ECG
2. Assess patient symptoms/ Hemodynamic impact on the patient
3. Act with correct interventions (drugs, defibrillation, pacing)
1.1 Basic ECG Components
P wave → Atrial Depolarization
PR interval (0.12–0.22s) → Conduction from Atria → Ventricles
QRS complex (<0.12s) → Ventricular Depolarization
ST segment → Early Repolarization
T wave → Ventricular Repolarization
ECG paper Key
Thin Lines: 1 mm intervals or 0.04
sec
Thick lines: 5 mm intervals or .2sec
1 thick lined box (5 small boxes) =
.20 sec or 5mm
5 thick lines boxes (25 small boxes)
= 1 second
10 mm = 1 Mv
Tick Marks on ECG paper rhythm
strip: 3 secs
Always check:
Normal Intervals Rate → Rhythm → P waves → QRS
width → Symptoms.
,Drills (Fill-in-the-Blank)
1. The QRS complex represents ____________________.
2. The P wave shows ____________________.
3. A prolonged PR interval indicates ____________________.
4. The normal heart rate range is ____________________.
5. The first step in interpreting an ECG is ____________________.
Mini Clinical Case Example
Patient: 56-year-old male, ECG shows rate 48 bpm, regular rhythm, P waves
upright before each QRS, asymptomatic.
Likely rhythm: Sinus bradycardia
Rhythm: Regular
Rate: 50bpm (norml range=60-100bpm)
P Waves: Upright and Regular
P-R Interval: 0.16 sec (normal range=0.12-0.20), one P wave for each QRS
QRS: 0.08 sec (normal range=0.04-0.12)
Management: Observe if asymptomatic.
If symptomatic, give Atropine 0.5mg IV. Or pacing
, NCLEX/Relias-Style Questions (30)
Section A: General ECG Knowledge
Q1. Which part of the ECG represents atrial depolarization?
A. P wave
B. PR interval
C. QRS complex
D. T wave
✅ Answer: A. P wave
Q2. The normal PR interval is:
A. 0.04–0.10s
B. 0.12–0.20s
C. 0.20–0.30s
D. 0.30–0.40s
✅ Answer: B. 0.12–0.20s
Q3. A widened QRS (>0.12s) usually indicates:
A. Atrial problem
B. Ventricular conduction delay
C. Normal finding
D. SA node block
✅ Answer: B. Ventricular conduction delay
Q4. Which electrolyte abnormality can cause peaked T waves?
A. Hypokalemia
B. Hyperkalemia
C. Hypocalcemia
