,Chapter 01 - Getting Started
1. In a three-dimensional (3D) CAD drawing, the location of an object such as a line can be
defined by specifying X, Y, and Z values.
A) True
B) False
2. Angles are measured in a clockwise direction in AutoCAD by default.
A) True
B) False
3. Drawing dimensions must be enlarged or reduced to a standard scale to fit on the
computer screen.
A) True
B) False
4. A CAD drawing is always viewed in its entirety (you can always see all of the drawing on
the screen).
A) True
B) False
5. A CAD drawing is considered a virtual, full-sized object, no matter how large the objects
in the drawing may be.
A) True
B) False
6. When you begin drawing for the first time, the workspace that appears in the Drawing
Editor is called the Drawing workspace. This workspace offers functions for creating 2-
dimensional (2D) and 3-dimensional (3D) drawings.
A) True
B) False
7. The Menu Bar is located along the top of the screen and consists of tabs, panels and
tools. For example, selecting the Home tab produces the Draw, Modify, Annotation, Layers,
Block and other panels.
A) True
B) False
8. In the Menu Bar, commands that invoke a dialog box end with ellipsis points (…).
A) True
B) False
9. The shortcut menu that appears when you right-click during a command is different
than the one that appears when no command is in progress.
A) True
B) False
10. Layouts, sometimes known as paper space, are used for creating 2D geometry. The
Model tab, sometimes known as model space, is used for creating 3D geometry.
A) True
B) False
1
,11. In AutoCAD, the default setting direction "straight down" would be measured as ____
degrees.
A) 0
B) 90
C) 180
D) 270
12. The rule for creating CAD drawings is that a computer drawing should be created ____
using real-world units.
A) true size
B) proportional to the size of the screen
C) to a proportion of the actual object
D) to a standard scale
13. The Coordinate Display gives the ____.
A) layer name and color
B) scale of the drawing
C) position of the cursor (crosshairs)
D) measurements of the screen
14. The Application Menu contains ____.
A) the coordinates display
B) a series of pull-down menus along the top of the Drawing Editor
C) a list of options for managing drawing files
D) tabs, panels and tools (buttons)
15. A shortcut menu is activated by ____.
A) selecting an item from the Menu Bar with ellipsis (…).
B) holding down the Ctrl key and clicking inside a dialog box
C) pressing the right mouse button
D) clicking inside a dialog box
16. In order to cancel a command, press the ____ key(s).
A) F1
B) Ctrl+Alt+Del
C) Esc (escape)
D) Break
17. Ortho (F8) is used to ____.
A) make the crosshairs "jump" to regular intervals
B) force lines to a horizontal or vertical alignment
C) straighten crooked lines
D) display the current cursor location
18. Polar Tracking (F10) makes it easy to ____.
A) draw lines at regular angular increments
2
, B) track the coordinate position of the cursor
C) force lines to either vertical or horizontal alignment
D) “snap” to regular intervals
19. Grid (F7) can be turned On to ____.
A) display the current location of the cursor
B) give a reference of units of length (dots) on a plotted or printed drawing
C) display a visual reference of units of length on the screen
D) change the Limits of the drawing area
20. The primary difference between model space and a Layout tab(s) is ____.
A) the color of the background
B) model space is used for drawing in 3D and a Layout is used for drawing in 2D
the Model tab displays the drawing you are copying from and the Layout tab is
C)
where you lay out the new drawing
model space is where you create the drawing and a Layout tab represents the sheet
D)
that you will plot or print on
3
,Answer Keys
Question Answer Question Answer
1 A 11 D
2 B 12 A
3 B 13 C
4 B 14 C
5 A 15 C
6 B 16 C
7 B 17 B
8 A 18 A
9 A 19 C
10 B 20 D
4
,Chapter 02 - Working with Files
1. When you use Open to open a drawing, a dialog box lets you "see" and choose the
drawing you want.
A) True
B) False
2. If you want to save a drawing to a flash drive, save it directly to the flash drive—you do
not have to worry about saving it to the hard drive.
A) True
B) False
3. The Open command produces a list of Recent Documents to easily locate and open
existing drawings; however, there is no recent document list available from the Application
Menu.
A) True
B) False
4. When you Open an existing drawing and are presented with the Select File dialog box,
you can highlight the desired drawing name and select OK or you can double-click on the
desired drawing name.
A) True
B) False
5. You can use SaveAs to save an AutoCAD drawing in another format such as an earlier
version of AutoCAD .DWG format.
A) True
B) False
6. To open, save, or start a new drawing, you have to switch out of AutoCAD and use
Windows Explorer.
A) True
B) False
7. If you accidentally delete a .DWG file, the related .BAK (backup) drawing file can be
opened directly using the Open command.
A) True
B) False
8. In case of an unexpected or accidental shutdown, such as a power outage, drawings
that were open when the shutdown occurred often can be recovered.
A) True
B) False
9. The Closeall command is used to close all the open drawings and shut down AutoCAD.
A) True
B) False
10. AutoCAD drawings can be saved as a .DWG or .DWT file type.
A) True
B) False
1
,11. The commands related to managing AutoCAD drawings and other files are located in
the ____ menu.
A) Drawings
B) Application
C) Draw
D) Management
12. It is recommended to use the Save command periodically during a drawing session
about every ____.
A) time you draw a Line
B) day
C) 15 or 20 minutes
D) minute
13. A typical drawing session would involve using ____ to begin work, ____ is used
periodically, and ____ is used for the final save and to end the session.
A) Recover, Save, Exit
B) New or Open, Save, Exit
C) New, SaveAs, Quit
D) Begin, Save, Exit
14. The ____ command allows you to store the current drawing with a new file name.
A) New
B) SaveAs
C) Recover
D) Name
15. If you want to begin a new drawing and use an existing template, use the ____
command.
A) Template
B) Open
C) New
D) SaveAs
16. When the current drawing has been named, using the Save command actually causes
AutoCAD to perform a ____.
A) Savequick
B) Qsave
C) 2save
D) Saveas
17. If you wanted to search for an existing drawing file and see a preview of the drawing,
use the ____.
A) Search command
B) Open command
C) List command
D) Windows Explorer
2
,18. If you use Open Read-Only to open an existing drawing, you can only ____.
A) open a drawing file for viewing, but you cannot edit the file
B) automatically Save the previous drawing before opening the new one
C) automatically close the previous drawing before opening the new one
D) ask if you want to Save Changes? before automatically closing the previous drawing
19. A drawing with a Digital Signature assigned ensures the drawing ___.
A) can be opened by entering the correct password
B) can be opened only by anyone else with a verified Digital Signature
C) can be opened only by using Recover
D) is original and has not been changed in any way
20. The Qnew command is intended to immediately begin a new drawing using ___.
A) the Start from Scratch option
B) the Create New Drawing dialog box
C) the template file specified in the Options dialog box
D) a Wizard
3
, Answer Keys
Question Answer Question Answer
1 A 11 B
2 B 12 C
3 B 13 B
4 A 14 B
5 A 15 C
6 B 16 B
7 B 17 B
8 A 18 A
9 B 19 D
10 A 20 C
4
