,TESTBANK for Ansys Workbench Tutorial Release
2024 By Kent L. Lawrence
Notes
1- The file is chapter after chapter.
2- We have shown you few pages sample.
3- The file contains all Appendix and Excel sheet
if it exists.
4- We have all what you need, we make update
at every time. There are many new editions
waiting you.
5- If you think you purchased the wrong file You
can contact us at every time, we can replace it
with true one.
6- Test Bank Solutions at the End of the Chapter
Our email:
,Chapter 01 - Ansys Mechanical I
1. Select the items that comprise a typical finite element part analysis process.
A) Simulation
B) Element tuning
C) Solid modeling
D) Optimization
2. Unfortunately, Ansys Workbench software does not include an online help system.
A) True
B) False
3. The finite element process generally involves three steps: Preprocessing, Equation
Solution, and Postprocessing.
A) True
B) False
4. The FEM software is so comprehensive that it is usually not necessary to critically
review the computed results.
A) True
B) False
5. Calculated FEM problem results include the following (select all that apply).
A) Elastic modulus
B) Cost
C) Deformation
D) Temperature
E) Strain
F) Stress
6. Twenty node brick elements give more accurate results than eight node brick elements.
A) True
B) False
7. Singular points are points in a model where the calculated stress is not representative of
the true stress at that point.
A) True
B) False
8. Uniform mesh refinement is always the most economical way to achieve an accurate
solution.
A) True
B) False
9. ANSYS Workbench provides only one way to import a part geometry from a CAD system.
A) True
B) False
1
, 10. If the part is symmetric with respect to a plane, only a symmetric portion need be
modeled even if the boundary conditions are not symmetric.
A) True
B) False
2
