,Chapter 01 - Getting Started
1. Once the Start button has been selected:
A) Autodesk Inventor will begin loading up immediately
B) The computer will begin the shutdown phase
C) A pop-up menu of the programs that are installed on the computer will appear
D) None of the above
2. Once the New icon has been selected:
A) The Create New File dialog box will appear
B) Left click on Standard.iam
C) Left click on Sheet Metal.iam
D) Left click on Weldment.iam
3. To begin a drawing:
A) Left click on Begin Drawing
B) Left click on the 3D Model tab.
C) Select XY Plane
D) Left click on the yellow banner
4. The Perpendicular symbol:
A) Signifies that a vertical line is exactly 90 degrees to a horizontal line
B) Signifies that a vertical line is cutting though the center of a circle
C) Signifies that a vertical line is not exactly 90 degrees to a horizontal line
D) None of the above
5. When using the Dimension tool, after geometry has been selected:
A) The dimension will appear in zeros
B) The Edit Dimension dialog box will appear
C) The dimension box will appear blank
D) The dimension will be attached to the cursor
6. To edit a dimension:
A) Enter the dimension in the Search Help Commands box in the upper right corner
B) Enter the dimension in the Edit Dimension dialog box
C) Enter the dimension in the Create Dimension dialog box
D) None of the above
7. To delete a line in a Sketch:
A) Left click on the line, A pop up menu will appear, left click on Erase
B) Right click on the line, A pop up menu will appear, left click on Erase
C) Right click on the line, A pop up menu will appear, left click on Delete
D) Left click on the line, A pop up menu will appear, left click on Delete
8. To exit the Sketch Panel:
A) Left click on Depart Sketch Panel
1
, B) Left click on Exit Sketch Panel
C) Left click on Finish 2D Sketch or Finish Sketch Exit
D) Right click on Exit Sketch Panel
9. A hole that does not utilize the Hole Wizard can be created using:
A) The Extrude Cut command
B) The Create Hole command
C) The Remove Curricular Material command
D) None of the above
10. The Hole Wizard requires:
A) the center of a Fillet radius as a center point
B) the use of the Extrude-Cut command
C) A starting point for a hole
D) A point on a surface
2
, Answer Keys
Question Answer Question Answer
1 C 6 B
2 A 7 C
3 B 8 C
4 A 9 A
5 D 10 D
3
