, TESTBANK for Design Workbook Using
SOLIDWORKS 2025 By Ronald E. Barr
Notes
1- The file is chapter after chapter.
2- We have shown you few pages sample.
3- The file contains all Appendix and Excel sheet
if it exists.
4- We have all what you need, we make update
at every time. There are many new editions
waiting you.
5- If you think you purchased the wrong file You
can contact us at every time, we can replace it
with true one.
6- Test Bank Solutions at the End of the Chapter
Our email:
,Lab 01 - Basic 2D Sketching
1. Using the Hide/Show drop-down command you can turn on or off the visibility of the
geometric relations in a sketch.
A) True
B) False
2. The Dynamic Mirror command will:
A) Select the sketch and make a copy of it about the origin.
B) Create a second sketch with a left hand copy of the original sketch.
C) Automatically draw a mirror image about the pre-selected mirror line.
D) Ask which geometric elements you wish to mirror.
3. The Blind end condition allows you to enter the distance of the extrusion or cut’s depth.
A) True
B) False
4. A sketch Fillet will:
A) Add a line perpendicular to the two pre-selected lines
B) Add a line to eliminate a corner in a sketch
C) Delete a line and replace it with a tangent arc
D) Round a corner in a sketch
5. You can only have one template with pre-set units.
A) True
B) False
6. Select all valid Geometric Relations available in a sketch.
A) Parallel
B) Horizontal
C) Equal
D) Concentric
7. A Circular Sketch Pattern allows you to:
A) Mirror sketch elements about a plane
B) Copy sketch elements about a centerline
C) Copy sketch elements about a center point
D) Copy sketch elements along a line or edge
8. When you create a Revolved Boss/Base, if you have a single centerline in the sketch it
will be automatically selected as the axis of revolution.
A) True
B) False
9. After you create a Boss Extrude or Revolved Boss, you cannot modify the sketch
anymore.
A) True
B) False
1
,10. When editing a sketch, the Rebuild button will:
A) Undo the last Dimension’s change
B) Exit the sketch and cancel any changes made
C) Exit the sketch and update the geometry
D) Exit SOLIDWORKS and save your work
2
, Answer Keys
Question Answer Question Answer
1 A 6 ABCD
2 C 7 C
3 A 8 A
4 D 9 B
5 B 10 C
3
