,Chapter 01 - Getting Started
1. Historically, SOLIDWORKS has not been backward compatible. In recent versions, has
SOLIDWORKS introduced any backward compatibility?
A) Yes, but only with specific recent versions.
B) Yes, compatible with all previous versions.
C) No, not compatible with any previous version.
2. What does IPS stand for when defining units?
A) Inch-Pound-Second
B) Include-Percent-Sign
C) Interesting Personal Space
3. What are the two necessary steps before you can begin sketching?
A) Select the plane to sketch on, and pick the Sketch icon.
B) Pick a surface to sketch on, then pick the Sketch icon.
C) Pick a surface, then select the dimension tool.
D) Pick the sketch icon, and select the Line tool to draw a line.
4. What does this sketch relation indicate?
A) The line is coincident with another line.
B) The line is at a 45-degree angle.
C) The curve is tangent to another curve.
D) The line is tangent to a curve.
5. How do you change the length of a line that already has a dimension associated with it?
A) Delete the dimension, and add a new dimension.
B) Double-click on the dimension, and enter a new value followed by <Enter>.
6. How do you get out of sketch mode?
A) Pick this icon.
B) Press the <Esc> key.
C) Pick this icon.
7. What does this icon mean?
A) Edit Part
B) Save
C) Save As
8. Where is the FeatureManager Design Tree located on the screen?
A) Left side of the screen
B) Right side of the screen
1
, C) Top of the Screen
9. Which of the following things are shown in the FeatureManager Design Tree?
A) Front plane
B) Annotations
C) Overall size of the part
D) Last date modified
E) Material
10. How do you assign Plain Carbon Steel to the part you just created?
A) Left-click on Material in the FeatureManager Design Tree, pick Plain Carbon Steel.
B) Type Material, then enter the name of the material to be assigned.
C) Right-click on Material in the FeatureManager Design Tree, pick Plain Carbon Steel.
2
,Answer Keys
Question Answer Question Answer
1 A 6 C
2 A 7 B
3 AB 8 A
4 CD 9 ABE
5 B 10 C
3
, Chapter 02 - Sketch Commands
1. What does this sketch tool allow the user to do?
A) Draw a 3-point Parallelogram
B) Draw a 3-point Center Rectangle
C) Draw a 3-point Corner Rectangle
2. What is an easy way to erase the entire sketch?
A) Type <Ctrl>-A followed by <Delete>
B) Press the <Delete> key
C) Exit SOLIDWORKS and begin again
3. What does this sketch tool allow the user to do?
A) Add lines at an angle to the sketch
B) Add dimensions to the sketch
4. What does this tool do if an entity is highlighted?
A) Create a three-dimensional Linear Pattern
B) Create a one-dimensional Linear Pattern
C) Create a two-dimensional Linear Pattern
5. What does this icon do to the highlighted entity?
A) Converts a sketch element into a construction entity.
B) Moves a line from one location to another.
C) Converts a construction entity into a sketch element.
6. How do you know if a dimension for a curved line is a radius?
A) The dimensional value starts with the letter “R”
B) The dimensional value starts with the symbol “ϕ”
C) The dimensional value ends with the letter “R”
7. What does it indicate if a portion of your sketch is shaded?
A) You have the 3-D shaded feature activated.
B) It is a closed section.
C) It is an open section.
8. How do you dimension the angle between two lines using the dimension tool?
A) Pick the first line, hold down the <Ctrl> key, and pick the second line.
B) Pick the first line, then pick the second line.
C) Pick the intersection of the two lines, then move away from that point.
