, TESTBANK for Engineering Design with
SOLIDWORKS 2025 By David C. Planchard
Notes
1- The file is chapter after chapter.
2- We have shown you few pages sample.
3- The file contains all Appendix and Excel sheet
if it exists.
4- We have all what you need, we make update
at every time. There are many new editions
waiting you.
5- If you think you purchased the wrong file You
can contact us at every time, we can replace it
with true one.
6- Test Bank Solutions at the End of the Chapter
Our email:
,Chapter 01 - Overview of SOLIDWORKS and the
User Interface
1. Identify the three default Reference planes in SOLIDWORKS.
A) Left plane
B) Right plane
C) Front plane
D) Top plane
2. The three default Reference Planes represent infinite 2D planes in 3D space. Planes
have no thickness or mass.
A) True
B) False
3. The sketch color black indicates a sketch is ___________ defined. It does not have a
negative (-) or positive (+) symbol in the Part FeatureManager.
A) fully
B) never
C) under
D) over
4. The sketch color blue indicates a sketch is ___________ defined. It has a negative (-)
symbol in the Part FeatureManager.
A) never
B) fully
C) under
D) over
5. The sketch color red/orange indicates a sketch is ___________ defined. It has a plus (+)
symbol in the Part FeatureManager.
A) fully
B) under
C) over
D) never
6. Use the Part FeatureManager Design Tree rollback bar to temporarily roll back to an
earlier state, to absorbed features, roll forward, roll to previous, or roll to the end of the
FeatureManager design tree.
A) True
B) False
7. In SOLIDWORKS, it is not necessary to fully dimension or define sketches before you use
them to create features. You should fully define sketches before you consider the part
finished for manufacturing.
A) True
B) False
8. Identify two default tabs in the SOLIDWORKS Task Pane.
A) View Palette
1
, B) Appearances, Scenes and Decals
C) PropertyManager
D) FeatureManager
9. In SOLIDWORKS, a 2D profile is called a feature.
A) True
B) False
10. In a sketch, first add geometric relations, then dimensions. This keeps the user from
having too many unnecessary dimensions. This also helps to show the design intent of the
model.
A) True
B) False
2
