, TESTBANK for SOLIDWORKS 2025 Advanced
Techniques By Paul Tran CSWE
Notes
1- The file is chapter after chapter.
2- We have shown you few pages sample.
3- The file contains all Appendix and Excel sheet
if it exists.
4- We have all what you need, we make update
at every time. There are many new editions
waiting you.
5- If you think you purchased the wrong file You
can contact us at every time, we can replace it
with true one.
6- Test Bank Solutions at the End of the Chapter
Our email:
,Chapter 01 - Introduction to 3D Sketch
1. A 3D-sketch consists of lines and arcs, circles, and splines.
A) True
B) False
2. When working in a 3D-sketch, a graphical assistant is provided to help you maintain
your orientation while you sketch on several planes. What is this assistant called:
A) 3D Sketch Handle
B) Space Handle
C) XYZ Orientation
3. While sketching in 3D-sketch, which hotkey is used to switch from one plane to the next,
from Front plane to Top plane, or from Top to Right plane:
A) Control
B) Shift
C) Tab
D) Alt
4. To make the dimensions parallel to the lines, while adding the dimension, select a line
and an endpoint, instead of selecting the 2 end endpoints.
A) True
B) False
5. When creating a sweep using the Circular-Profile option, you will need to:
A) Sketch a circle
B) Enter a diameter dimension
C) Select the circular profile
D) Do nothing
6. In SOLIDWORKS, a helix is recognized as:
A) a circle
B) a 3D sketch
C) a 2D sketch
D) a 3D curve
7. In 3D-Sketch, which relation is used to snap the end point of a line to a helix:
A) Coincident
B) Merge
C) Pierce
D) Perpendicular
8. Which command is used to join the sketch entities with 3D curves:
A) Merge Result
1
, B) Join bodies
C) Composite Curve
D) None of the above
9. When a line and a plane are selected, the On-Plane relation will make the line:
A) Parallel to a plane
B) Coincident to the plane
C) Perpendicular to a plane
D) None of the above
2
, Answer Keys
Question Answer Question Answer
1 A 6 D
2 B 7 C
3 C 8 C
4 A 9 B
5 B
3
