, Chapter 01 - Overview of SOLIDWORKS and the
User Interface
1. Identify the three default Reference planes in SOLIDWORKS.
A) Right plane
B) Left plane
C) Front plane
D) Top plane
2. The three default Reference Planes represent infinite 2D planes in 3D space. Planes
have no thickness or mass.
A) True
B) False
3. The sketch color black indicates a sketch is ___________ defined. It does not have a
negative (-) or positive (+) symbol in the Part FeatureManager.
A) fully
B) never
C) under
D) over
4. The sketch color blue indicates a sketch is ___________ defined. It has a negative (-)
symbol in the Part FeatureManager.
A) under
B) over
C) never
D) fully
5. The sketch color red/orange indicates a sketch is ___________ defined. It has a plus (+)
symbol in the Part FeatureManager.
A) under
B) fully
C) never
D) over
6. Use the Part FeatureManager Design Tree rollback bar to temporarily roll back to an
earlier state, to absorbed features, roll forward, roll to previous, or roll to the end of the
FeatureManager design tree.
A) True
B) False
7. In SOLIDWORKS, it is not necessary to fully dimension or define sketches before you use
them to create features. You should fully define sketches before you consider the part
finished for manufacturing.
A) True
B) False
8. Identify two default tabs in the SOLIDWORKS Task Pane.
A) Appearances, Scenes and Decals
1
