,SOLUTION MANUAL Parametric Modeling with
SOLIDWORKS 2025 By Paul J. Schilling
Notes
1- The file is chapter after chapter.
2- We have shown you few pages sample.
3- The file contains all Appendix and Excel sheet
if it exists.
4- We have all what you need, we make update
at every time. There are many new editions
waiting you.
5- If you think you purchased the wrong file You
can contact us at every time, we can replace it
with true one.
6- Test Bank Solutions at the End of the Chapter
Our email:
, Parametric Modeling SolidWorks 2025 Solution Manual 1
Ch. 2 Review Questions:
1. What is the first thing we should set up in SOLIDWORKS when creating a new
model?
When starting a new CAD file, the first thing we should do is choose the units we
would like to use.
2. Describe the general parametric modeling procedure.
a. Create a rough two-dimensional sketch of the basic shape of the base feature
of the design.
b. Apply/modify constraints and dimensions to the two-dimensional sketch.
c. Extrude, revolve, or sweep the parametric two-dimensional sketch to create
the base solid feature of the design.
d. Add additional parametric features by identifying feature relations and
complete the design.
e. Perform analyses on the computer model and refine the design as needed.
f. Create the desired drawing views to document the design.
3. What is the main difference between a rough sketch and a profile?
As the name implies, a rough sketch is not precise at all; while a profile is the
completed and precise sketch that is used to create the solid feature.
4. List two of the geometric constraint symbols used by SOLIDWORKS.
Parallel indicates a line is parallel to other entities
Perpendicular indicates a line is perpendicular to other entities
5. What was the first feature we created in this lesson?
The first feature we created in this lesson was an extruded feature.
6. Identify the following commands:
(a)
Shaded with Edges – Allows the display of a shaded view of a 3D
model with its edges.
(b)
Sketch - Allows the creation of a new sketch.
, Parametric Modeling SolidWorks 2025 Solution Manual 2
(c)
The Circle command - Allows the creation of a circle.
(d)
The Rectangle command - Allows the creation of a rectangle.
