NFPA 24 Test (TFM10) Exam
NFPA 24 TEST (TFM10) EXAM NEWEST 2025/2026 COMPLETE
ALL QUESTIONS AND CORRECT DETAILED ANSWERS (VERIFIED
ANSWERS) |ALREADY GRADED A+||BRAND NEW VERSION!
A connection through which the fire department can pump supplemental water
into the sprinkler system, standpipe, or other water-based fire protection systems,
thereby supplementing existing water supplies. - ANSWER-Fire Department
Connection
A pump that is a provider of liquid flow and pressure dedicated to fire protection.
- ANSWER-Fire Pump
An enclosure located over or adjacent to a hydrant or other water supply designed
to contain the necessary hose nozzles, hose wrenches, gaskets, and spanners to
be used in fire fighting in conjunction with and to provide aid to the local fire
department. - ANSWER-Hose House
The hose connection outlet of a hydrant. - ANSWER-Hydrant Butt
The water flow rate for a system or hose stream that has been calculated using
accepted engineering practices. - ANSWER-Hydraulically Calculated Water
Demand Flow Rate
The hydrant outlet intended to be connected to a fire department pumper for use
in taking supply from the hydrant. - ANSWER-Pumper Outlet
1|Page
, NFPA 24 Test (TFM10) Exam
The flow, either measured or calculated, that is available from a hydrant at the
designated residual pressure (rated pressure). - ANSWER-Rated Capacity
The maximum anticipated static (nonflowing) or flowing pressure applied to fire
protection system components exclusive of surge pressures and exclusive of
pressure from the fire department connection. - ANSWER-System Working
Pressure
A test performed by the flow and measurement of water from one hydrant and
the static and residual pressures from an adjacent hydrant for the purpose of
determining the available water supply at that location. - ANSWER-Flow Test
A test of a piping system using flow rates intended to remove debris from the
piping system prior to it being placed in service. - ANSWER-Flushing Test
A test of a closed piping system and its attached appurtenances consisting of
subjecting the piping to an increased internal pressure for a specified period of
duration to verify system integrity and leak rates. - ANSWER-Hydrostatic Test
The pressure that exists in the distribution system, measured at the residual
hydrant at the time the flow readings are taken at the flow hydrants. - ANSWER-
Residual Pressure
The pressure that exists at a given point under normal distribution system
conditions measured at the residual hydrant with no hydrants flowing. - ANSWER-
Static Pressure
2|Page
, NFPA 24 Test (TFM10) Exam
A valve that allows flow in one direction but prevents flow in the opposite
direction. - ANSWER-Check Valve
A valve that has components that show if the valve is open or closed. Examples
are outside screw and yoke (OS&Y) gate valves and underground gate valves with
indicator posts. - ANSWER-Indicating Valve
Fire hydrant that has its operating valve located at the base or foot of the hydrant
rather than in the barrel of the hydrant. When operating properly, there is no
water in the barrel of the hydrant when it is not in use. These hydrants are used in
areas where freezing may occur. - ANSWER-Dry-Barrel Hydrant
The hydrant that is used for the flow and flow measurement of water during a
flow test. - ANSWER-Flow Hydrant
A valved connection on a water supply system having one or more outlets that is
used to supply hose and fire department pumpers with water on private property.
- ANSWER-Private Fire Hydrant
A valved connection on a water supply system having one or more outlets that is
used to supply hose and fire department pumpers with water. - ANSWER-Public
Hydrant
The hydrant that is used for measuring static and residual pressures during a flow
test. - ANSWER-Residual Hydrant
3|Page
, NFPA 24 Test (TFM10) Exam
A hydrant used in areas that are NOT susceptible to freezing. The barrel of the
hydrant is normally filled with water. - ANSWER-Wet-Barrel Hydrant
________________hydraulic calculations shall show that the main is able to
supply the total demand at the appropriate pressure. - ANSWER-Private fire
service main's
Tanks shall be installed in accordance with. - ANSWER-NFPA 22
The connection from the hydrant to the main shall not be less than_____. -
ANSWER-6 in
Where post indicator valves are used, they shall be set so that the top of each
post is____________ above the final grade. - ANSWER-32-40 in
Hydrants shall be located not less than _______ from the building being
protected. - ANSWER-40 ft
Where hydrants located closer than 40ft to the building, shall be permitted to be
used where approved by the_____. - ANSWER-AHJ (authority having jurisdiction)
The center of a hose outlet located in a hose house shall not be less than _______
above the final grade. - ANSWER-18 in
The center of a hose outlet shall not be more than____above the floor of a hose
house. - ANSWER-12 in
4|Page
