MEGR 3231 FINAL EXAM QUESTIONS
WITH 100% CORRECT ANSWERS
LATEST VERSION 2025/2026.
What is CAD?
What are two types of CAD? - ANS Computer Aided Design
The implementation of computers in the creation. modification, analysis, and optimization of a
design.
Drafting and Modeling
What is CAM?
What are 3 types of CAM? - ANS Computer Aided Manufacturing
Application of computers to the creation and assembly of physical components.
NC - "Numerical control" of computer driven machine tools.
1 @COPYRIGHT 2025/2026 ALLRIGHTS RESERVED.
,RP/AM - Rapid Prototyping / Additive Manufacture
CAPP - Computer Aided Process Planning
What is CAE?
What are 3 types of CAE? - ANS Computer Aided Engineering
FEA - Finite Element Analysis. Can be mechanical of thermal. The mechanical analysis can be
static or dynamic.
CFD - Computational Fluid Dynamics
Simulations.
CAD Research in the 50's - ANS CNC Programming
CAD Research in the 60's - ANS Sketchpad [Ivan Sutherland]
Describe Sketchpad {Ivan Sutherland] - ANS Object oriented programming
Computer power was finally available
2D sketches
Horizontal and vertical line, arcs, zoom capability
2 @COPYRIGHT 2025/2026 ALLRIGHTS RESERVED.
,More of computer aided drawing and drafting
CAD Research in the 70's - ANS Corporate Development
Computer Power Advances
(Super computers are room sized)
What were some CAD software companies in the 70's - ANS -Unigraphics
-AutoTrol
-CATIA
-Computervision > Sun > Prime
CAD Research in the 80's - ANS Software Companies
What were some CAD software companies in the 80's - ANS Autodesk
Bentley
Dassault
Parametric Technology
What are the forms of 2D CAD? - ANS Raster
Vector
What are the forms of 3D CAD? - ANS Surface
Solid
3 @COPYRIGHT 2025/2026 ALLRIGHTS RESERVED.
, Wireframe
What is raster?
1 bit and 3 bit - ANS A field of points that can be turned on and off with different colors. The
whole field presents a complete graphic. Think of it like an image. (bitmap)
Depth of color depends on memory in bits per pixel.
1 bit (Monochrome)
Black or White, 1 on-off switch
3bit (Primaries)
Each pixel has 3 on-off switches
**SCALING CAUSES DISTORTION**
What is vector? - ANS A set of simple geometric features with mathematical features.
Can be scaled without distortion
Describe Electronic Engineering Drawings - ANS Allows for easier drawing modification and
duplication.
Simplifies the transfer of data
Reduce paper use [Not really though]
