NEIEP 800 FINAL EXAM QUESTIONS
AND ANSWERS GRADED A+ 2025/2026
Hydro elevators in low rise applications do not need an _____ _____ room. - ANS overhead
machine
Some advantages of hydros are lower equipment and building construction costs because the
load of a hydro is carried to the _____ where as the load of a traction car is carried by the _____
_____. - ANS ground, building structure
When drilling the jack hole, the only proper way to determine if the hole is plumb is to remove
the drill stem and bit and use a _____ _____. - ANS Spider Bob
To plumb the hole, a spider bob is attached to a length of piano wire suspended from as near as
possible to the top of the _____ or from a fixed point on the drill rig. - ANS Hoistway
When welding a joint, lay _____ inch tack welds _____ degrees apart, shift it 90 degrees and lay
two more 1 inch tack welds 180 degrees apart. - ANS 1, 180
On power units having the motor beneath the tank, the pump may be either _____ driven or
_____ coupled. - ANS belt, direct
1 @COPYRIGHT 2025/2026 ALLRIGHTS RESERVED.
, The purpose of the _____/_____ is to silence the effect of any pulsations in the pump output
and should be as close to the pump as possible. - ANS silencer, muffler
On Bolsters/Bolster Assembly, the plunger is fastened to the _____ _____ which is then
mounted to the center of the Bolster Assembly. - ANS platen plate
With wye-delta, reduced current starting is accomplished without the need for _____. -
ANS resistors
_____ run buttons should run the platform and sling at leveling speeds only. - ANS Temporary
A _____ _____ consists of a piston held closed by an adjustable spring and must open at a
certain pressure to prevent any further increase in pressure. - ANS relief valve
A _____ lowering valve allows the car to be lowered at a speed not exceeding 20fpm in case of
power failure. - ANS manual
As the oil temperature changes, the _____ will change as well and will effect the performance,
more specifically, the leveling and approach of the elevator. - ANS viscosity
Be sure wellways are properly _____ to avoid accidental injury to you, your team or anyone
working outside of our industry. - ANS barricaded
Barricades around the wellway must be _____ inches high and be capable of withstanding a
_____lb force. - ANS 42, 200
2 @COPYRIGHT 2025/2026 ALLRIGHTS RESERVED.
