Terms in this set (22)
Resultant force for triangular loading
Degrees of freedom for a pin support Rotation
What is a zero force member - A member that does not take force
- help with stability
- function of the location and orientation of the applied loads in the truss
- If the loading changes direction then the truss must be reanalyzed
4 rules of a zero-force member 1. If a joint has one 2 members with no forces applied at the joint, then both
members are 0-force
2. If a joint has 3 members, 2 of which are along the same line of action with
no force @ the joint, then the 3rd member is zero-force.
3. Once a 0-force member is identified using rule 1&2, assume the member
doesn't take any load and remove.
4. Geometry at the support can result in an additional 0-force members
