Structural Steel Welding ICC, ICC Codes, Save
ICC Flash Cards, ICC General
Requirements Practice Exam, ICC
Welding Practice Questions, ICC Bolting,
IRC/ICC EXAM 2021, Bolting Test #1, s1
bolts, ICC Structural Steel, s1 bolts, S1
Bolting, ICC Bolting
Terms in this set (1461)
A welding operator successfully Yes, that does not warrant requalification
completed performance
qualification using multiple SAW
electrodes. Can he weld using a
single SAW electrode?
What is the minimum length of a 4 times the nominal size of the fillet
fillet weld?
,Does the 5G welding position No
rotate during welding?
When using an FCAW reinforcing More than 10%
steel WPS, a requalification.
% increase in amperage requires
WPS requalification.
What's the acceptance criteria for Fracture can't occur in the weld or HAZ.
a bend test on a stud during stud
base qualification?
A fillet weld in a tubular 5/32-inch for a 1 inch length.
connection is specified to
measure 1/4-inch in size and 10
inches in length. What is the
minimum allowable fillet weld
size?
What does HAZ stand for? Heat affected zone.
A fillet weld in a tubular 3/4-inch for a 1/2-inch length.
connection is specified to
measure 7/8-inch in size and 5
inches in length. What is the
minimum allowable fillet weld
size?
A welder's PQR tests successfully Flat, horizontal, overhead
pass for a flare-V-groove weld
using sheet to sheet steel in the
overhead position. What
positions is the welder qualified
to weld in?
Special inspection tasks and AISC 360
frequencies are found in which
publication?
,A 1 inch thick test plate is welded 1/2 inch to 1.1 inches
with ESW using a CJP groove
welds for WPS qualification and
meets acceptance criteria. What
plate thickness range is qualified?
The D1.1 code is intended for Low Alloy
which of the following types of
steel?
According to AISC, the Inspector Each One
must document acceptance or
rejection of how many welded
connections in a structure?
A welder successfully welds a 1/8-inch
WPQR pipe test specimen for
production CJP Groove Butt
Joints using a 6 inch test pipe with
3/8" thick walls. What is the
minimum plate thickness
qualified?
What is the maximum fillet weld 3/16-inch
size along the edge in a lap joint
when the base metal is 1/4-inch
thick?
A welder was qualified using a No, omitting backing is an essential variable that requires him to
backing bar for a CJP groove requalify if changed.
weld on his WPQR test? Is he
qualified to weld a CJP groove
weld joint that does not have
backing but does have a qualified
WPS?
, EOR stands for: Engineer of Record
Name a prequalified welding SAW
process?
Studs less than 5/16-inch
in diameter can be furnished
without flux.
Which test position qualifies a 6GR
welder to weld in all positions for
production box tube welds on T,
Y, or K
connections?
For rebar welder qualification, 2 macroetch
what tests need to be conducted
on an indirect butt weld joint?
A 3/4-inch thick test plate is 1/8-inch to 1-1/2 inches
welded with a CJP groove weld
for WPS qualification and meets
acceptance criteria. What tubing
wall thickness is qualified for use
on a WPS?
What's the maximum amount of 1/8-inch
reinforcement for a groove weld
in a butt joint for #8 reinforcing
steel?
A PJP groove butt weld has a 1/2-inch
face width of 3/4-inch, a 1/2-inch
throat, and a 1/4-inch root face.
The base metals are each 1 inch
thick. What is the weld size?
Which of the following elements Reference Line
are required in a welding
symbol?
