Ironworker NCCER
Study online at https://quizlet.com/_bqpqle
1. ASSUMING A GRIP DISTANCE OF 1", WHAT IS THE MINIMUN LENGTH OF
THE BOLT REQUIRED FOR A 3/4" DIAMETER BOLT?: 2 1/4"
2. THE LOCATION OF BRIDGING DEPENDS ON THE LENGTH OF THE:: SPAN
3. BEFORE BUNDLES OF DECK CAN BE LANDED ON A BAR JOIST, WHAT
ACTION MUST BE COMPLETED?: JOIST MUST HAVE BRIDGING INSTALLED
4. WHEN MATERIALS ARE BEING HOISTED TO AN UPPER LEVEL, A TAG LINE
IS USED TO:: HELP CONTROL THE LOAD
5. ITEMS SUCH AS FIELD WELDING INSTRUCTIONS, HANGERS, AND CON-
NECTION DETAILS ARE GENERALLY FOUND ON:: THE DETAIL DRAWINGS
6. THE ABILITY OF A STRUCTURAL STEEL COMPONENT TO RESIST
PULLING FORCES IS KNOWN AS:: TENSILE STRENGHT
7. WHAT TYPE OF DECKING HAS IMPRESSIONS FORMED ON ITS RIB?: COM-
POSITE DECK
8. THE GROUND FLOOR ELEVATION IS SHOWN AS +100.25. THE ROOF TOP
ELEVATION IS SHOWN AS +130.50. WHAT IS THE DIFFERENCE IN ELEVA-
TION?: 30'3
9. IN WHAT DRAWING WOULD ONE FIND THE CORRECT BOLT SIZE FOR A
BEAM BEING BOLTED?: DETAIL DRAWING
10. WHAT SHOULD ALWAYS BE USED TO IGNITE A CUTTING TORCH?: STRIK-
ER
11. EQUILIZING THE WEIGHT OF THE LOAD AT VARIOUS LIFTING POINTS IS
CALLED:: CONFIGURATION
12. A COMBINATION SQUARE WITHOUT A PROTRACTOR HEAD IS USED TO
LAYOUT:: 45 DEGREE LINES
13. PRIOR TO INSPECTION IT IS GOOD PRACTICE TO TEST ALL STUDS WITH
WHAT METHOD?: PING TEST
14. WHERE IS THE FULCRUM OR PIVOT POINT ON A FORKLIFT?: THE FRONT
AXLE
15. A DOCUMENT THAT OUTLINES WEIGHTS,CRANE CONFIGURATION AND
RIGGING REQUIREMENTS FOR A LIFT IS CALLED AN:: LIFT PLAN
16. WHERE CAN THE BOLTING METHODS REGARDING STRUCTURAL STEEL
USUALLY BE FOUND ?: IN THE GENERAL NOTES OF THE STRUCTURAL
DRAWINGS
17. WHEN ESTABLISHING ELEVATIONS OF STRUCTURAL STEEL MEMBERS,
THE REFERENCE POINT USED TO DETERMINE ALL OTHER ELEVATIONS IS
CALLED?: THE BENCHMARK
18. WHAT IS THE SURFACE AREA OF A RECTANGLE WITH THE DIMENSIONS
OF 30'6" TALL AND 6 FEET WIDE?: 183FT
1/5
, Ironworker NCCER
Study online at https://quizlet.com/_bqpqle
19. MEASUREMENTS FROM THE CENTER OF THE CRANES AXIS OF ROTA-
TION TO THE CENTER OF THE LOAD LINE WITH THE LOAD APPLIED IS:: LOAD
RADIUS
20. WHICH OF THE FOLLOWING TOOLS WOULD BE USED TO PRY STEEL
INTO PLACE?: SLEEVER BAR
21. WHEN TRAVELING TO PICK UP A LOAD ALWAYS KEEP THE:: FORKS LOW
22. WHAT TYPE OF DRAWING SHOWS THE PRECISE DIMENSIONS OF A SEC-
TION OR PART OF THE LARGER PLAN?: DETAIL
23. WHAT IS THE PROPER WAT TO ATTACH TWO SLINGS TOGETHER?: USE A
SHACKLE
24. A FRICTION LIGHTER IS COMMONLY KNOWN AS A:: STRIKER
25. HOW MANY PIECES OF CHECKERED PLATE CAN BE LIFTED WHEN US-
ING PLATE GRABS?: NO MORE THAN ONE PLATE
26. WHAT IS THE MAXIMUM ALLOWABLE DEVIATION FROM A PLUMB LINE
FOR A SINGLE - COLUMN SHIPPING PIECE?: 1/1500
27. THE PROCESS OF STACKING TIMBERS IN ALTERNATE TIERS TO SUP-
PORT A HEAVY WEIGHT IS CALLED:: BLOCKING
28. PLUMBING UP GUYS SHOULD BE INSTALLED TO PLUMB UP A STRUC-
TURE AFTER:: ALL STEEL IS ERECTED
29. WHAT IS THE SURFACE AREA OF A TRIANGLE WITH A 12" BASE AND 10"
HEIGHT?: 60IN SQUARE
30. A SKIDMORE TESTER IS A DEVICE THAT MEASURES A BOLTS:: YIELD
PRESSURE
31. EXTENDABLE ARMS ATTACHED TO A CRANE BASE MOUNTING THAT
RELIEVE THE WHEELS OF CRANE WEIGHT AND PROVIDE STABILITY ARE
CALLED:: OUTRIGGERS
32. WHICH OF THE FOLLOWING ITEMS ARE USED FOR HEAVY RIGGING?: -
Slings, shackles, and spreader beam
33. WHAT IS USED TO PREVENT JOIST FROM MOVING LATERALLY?: -
X-BRIDGING
34. RESPIRATORS SHOULD BE USED IF WELDING: IN A CONFINED SPACE
35. THE BUILDINGS FRAME BEFORE BEING PERMANENTLY FASTENED
MUST BE:: PLUMB
36. WHAT DOES MSDS STAND FOR?: Material Safety Data Sheet
37. ALL OF THE FOLOWING ARE TRUE ABOUT THE SAFE USE OF SHACKLES
EXCEPT:: SCREW PINS SHOULD BE BACKED OFF TWO TURNS
38. WHY MUST THE CYLINDER VALVE BE "CRACKED" BEFORE A REGULA-
TOR IS CONNECTED TO AN OXYACETYLENE CYLINDER?: TO CLEAN THE
CYLINDER VALVE OF FOREIGN MATERIAL
2/5
